3 - Inserting the SIM card

To use your MAMBO2-B6 device you have to insert a valid SIM card (that supports SMS, Voice/Data and
GPRS). The SIM card must be either a 1.8 V or 3 V one. Older 5V SIM cards are not compatible with your
MAMBO2-B6 device.
Hint: The SIM card contains your subscription and your mobile number. The SIM card and its
contacts can be damaged by scratches or bending, so be careful when handling, inserting
or removing the SIM card.
Generally, your MAMBO2-B6-EVALKIT is shipped with a SIM card that is installed in the unit's SIM card
reader. If you would like to use another SIM card or there is no SIM card included, then follow the steps
below:
After the MAMBO2-B6 has been fully charged, disconnect it from the USB Desk Cradle and position

it so that the display is facing up and the SIM/Charge cover is facing you.
Open the the SIM cover (1).

With SIM microchip facing upward and with the bevelled corner oriented on the right side of SIM

insert your SIM card into the SIM card slot (in the upper interface). Thereafter, slide the SIM forward
until it fits into the slot (2).
Close the SIM cover (3).

To remove an inserted SIM card from its slot, first open the cover and then push the SIM card edge

with a pen, fingernail or other suitable pointed object until it jumps out.
Figure 3: Open the cover and install/remove the SIM card.
