Intuicom RTK Bridge-X Installation Manual page 5

Deutsch
3
6
1
4
4
Deutsch connector
(DTM06-12S)
pinout
• Using the Intuicom RTK Bridge-X to CFX 750 data/power cable (XRTKCAB-DD6)
connect the RTK Bridge-X data port to the B Port on the CFX 750.
• Power on 750 unit using power button on the upper right back of the display.
Version 1.0
Pin-out Diagram 1
Cable Color
Red
Receive (from RTK Bridge-X to
Green
Xmit (to RTK Bridge-X from
White
Black
Brown
Section 2: Installation Instructions
Signal
Power
remote device)
remote device)
Power Ground
Signal Ground
3
FMX D-Port
9
3
4
8
5
Intuicom, Inc.
