Lowrance StructureScan Installation Manual page 3

Transom Mount
(Page 6)
Jackplate Mount
(Page 7)
Step Mount
(Page 8)
Direct Mount/Step
(Page 9)
Trolling Motor Mount
(Sold separately)
(Page 10)
StructureScan Transducer Mounts
• Keeps transducer in the water when the boat is
on plane, allowing you to track bottom at high
speeds
• Transducer angle can be adjusted so it is parallel
with the water
• Transducer more likely to collide with obstructions
in the water and adds drag to the boat
• Transducer is not in the water when boat is on
plane; protects transducer and prevents drag
from transducer
• Transducer angle can be adjusted so it is parallel
with the water
• Allows you to mount transducer without drilling
holes in your boat
• Does not track bottom when boat is on plane
• Transducer is not in the water when boat is on
plane; protects transducer and prevents drag
from transducer
• Transducer angle can be adjusted so it is parallel
with the water
• Does not track bottom when boat is on plane
• Transducer is not in the water when boat is on
plane
• Protects transducer and prevents drag from
transducer
• Transducer angle can not be adjusted so it is
parallel with the water
• Does not track bottom when boat is on plane
• Allows you to scan areas by moving trolling
motor left/right
• Can only be used when trolling motor is in the
water
• Rotating trolling motor quickly will impact sonar
images
3
