π
H-1980
foot-operateD
Stapler
PAGE 1 OF 6
1-800-295-5510
uline.com
Before operating this stapler familiarize yourself with the safety
warnings and instructions in this manual. Keep these instructions with
the stapler for future reference. if you have any questions, contact
Uline at 1-800-295-5510.

Stapler SpecificationS

Dimensions L x W x H:
Weight (without fasteners):
Staple Specification:
Staple Specification:
Staple Capacity:
warning!
36 x 24 x 49"
66 lbs.
S-289 C58 Stick
S-1396 C34 Stick
200 Staples
0813 IH-1980
