SPECIFICATIONS
SUPPLY VOLTAGE.......................
CONTROL VOLTAGE...................
MOTOR ........................................
OPERATOR OUTPUT SPEED.........
( Operator only).........
NET WEIGHT
STANDARD WIRING TYPE............
In compliance
with UL325
4
GENERAL
115, 230 VAC single phase, 208, 460, 575 VAC three phase
24VAC class 2 transformer, 2 amp fuse type ACG
Continuous duty
1/2, 3/4, 1, 1 ½, 2 Horsepower (2HP is not available in single phase)
38 RPM
78 Lbs (35 Kg) for 1/2HP 115V Opera-GH model
C2-momentary contact to open and stop and
constant pressure to close.
DIMENSIONS
OGH
