Manaras Opera Opera-GH Installation And Instruction Manual page 22

Power Supply
115/208/230 VAC
1 Ph. 60 Hz
208/230/
460/575 VAC
3 Ph. 60 Hz
Open/Close
3
3
Open Only
PULLCORD003
NOTE
Interface Module Jumper
(TK8200)
Always set the jumper
located inside the
Interface Module on
N.O (Normally Open)
Black & white
White
1 2
24VAC (10VA MAX.) ONLY FOR THE
SUPPLY OF PHOTOCELLS, LOOP
DETECTORS, KEYPADS...
4
7
AIRSWITCH009
1 2 3
5 3 1 2
22
1 2 3 4
5
White
Green
2-wire Electric Sensing Edges
5
Black & white
White
6 7 8
9
3
5
STATION020
5
1 2 3
Circuit
5V DC
1
Blue
Brown 2
Orange
3
White
5
