Summary of Contents for Viega Multiplex Trio 6170.11
- Page 1 Multiplex Trio drain/overflow Visign MT9 Instructions for Use for bathtub with middle connection, water level increase plus 5 cm Model Year built: 6170.11 from 01/2015 en_INT...
- Page 2 Multiplex Trio drain/overflow Visign MT9 2 from 22...
-
Page 3: Table Of Contents
Table of contents Table of contents About these instructions for use Target groups Labelling of notes About this translated version Product information Intended use 2.1.1 Areas of use Product description 2.2.1 Overview 2.2.2 Technical data Accessories Handling Assembly information 3.1.1 Mounting conditions 3.1.2 Installation dimensions... -
Page 4: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 5: About This Translated Version
About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e. -
Page 6: Product Information
The drain/overflow is suitable for bathtubs with a middle connection. Detailed information regarding all bathtub models and the corre- sponding Viega drains / overflows can be found in the catalogue or on the Internet. Multiplex Trio drain/overflow Visign MT9... -
Page 7: Product Description
Product information Product description 2.2.1 Overview The following components are included in the scope of delivery of the Multiplex Trio drain / overflow: Fig. 1: Component overview overflow unit profile seal double seal seal flange cover supply flange Site protection fixing screw rotatable rosette 10 valve cone... -
Page 8: Technical Data
Product information 24 Bowden cable 25 sleeve 26 adapter 2.2.2 Technical data Drainage capacity (at an accumu- 0.92 l/s lation height of 300 mm) Overflow capacity (at an accumu- 0.55 l/s or 0.63 l/s lation height of 60 mm) Inlet capacity (at 0.25 MPa 20 l/min (2.5 bar)) Diameter of bathtub drain hole... - Page 9 Product information Optional accessories Multiplex extension set It is possible to extend the odour trap below the bathtub in the case of bathtubs with a very thick floor. The extension set, model 6161.7, is available for such cases. Multiplex Trio drain/overflow Visign MT9 9 from 22...
-
Page 10: Handling
Handling 3 Handling Assembly information 3.1.1 Mounting conditions The following requirements exist for the mounting of the drain / over- flow: The bathtub is installed. The drainage line is installed all the way to the bathtub. The underside of the bathtub is accessible. 3.1.2 Installation dimensions Fig. -
Page 11: Required Tools And Materials
Handling 3.1.3 Required tools and materials Tool The following tools are required for mounting: socket spanner (size 14) fine-toothed saw flat-blade screwdriver Material No additional material is required for the complete mounting of the product. Multiplex Trio drain/overflow Visign MT9 11 from 22... -
Page 12: Assembly
Handling Assembly 3.2.1 Mounting overflow Proceed as follows to the mounting of the overflow: Push the rubber sleeve onto the pipe of the overflow unit. The lower edge must be flush with the edge of the overflow pipe. Fit the profile seal in the overflow unit. If the wall thickness is smaller than 3 mm (in the case of steel bath- tubs), insert an addition seal between profile seal and bathtub. - Page 13 Handling Hold the overflow unit on the overflow opening of the bathtub from the outside. Insert the fixing screw in the flange. Screw the fixing screw in the overflow unit. NOTICE! Pliers or other tools may damage the fixing screw or the flange.
-
Page 14: Mounting The Drain
Handling 3.2.2 Mounting the drain Proceed as follows to mount the drain: Place the double seal onto the drain unit in such a way that the recess is positioned above the connecting pipe. Place the profile seal in the recess of the drain unit. Mount the drain unit with profile seal on the drain hole of the bathtub from below. -
Page 15: Connecting Overflow And Drain
Handling Insert the site protection. 3.2.3 Connecting overflow and drain After the overflow and the drain have been mounted, you must connect them both using the overflow pipe. Proceed as follows: Requirements: The overflow is mounted in the overflow opening. The drain is securely mounted on the base of the bathtub. -
Page 16: Connecting The Wastewater System
Handling 3.2.4 Connecting the wastewater system Proceed as follows to connect the drain/overflow to the wastewater system: Requirements: The overflow and drain units are installed on the bathtub. The connection between overflow and drain has been made. If the wastewater pipe only has a diameter of 40 mm, cut off drain elbow. -
Page 17: Connecting The Inlet
The overflow and the drain are connected. The connection to the wastewater system has been made. INFO! Mounting with the Viega plug connection is described in the following. Mounting can also be carried out with other con- necting materials. If necessary, observe the manufacturer's instructions. -
Page 18: Mounting Equipment Set
Handling 3.2.6 Mounting equipment set To avoid damage to the rosette and valve cone, only mount the equip- ment set after finishing all other work on the building site. Proceed as follows: Set the valve cone with the help of the adjusting screw and counter with the nut. -
Page 19: Leakage Test
Handling Remove the rotatable rosette. Fit the rotatable rosette with the flat side facing upwards. ð The rotatable rosette is properly aligned. 3.2.7 Leakage test The leakage test is only carried out as a visual inspection. Check the points marked in the following drawing with particular care: Check the drain/overflow fitting for visible leaks. -
Page 20: Use
Handling The drain / overflow are controlled via the rotatable rosette on the over- flow. Proceed as follows to open or close the drain: Turn the rotatable rosette to the left. ð The drain closes itself. Turn the rotatable rosette to the right. ð... - Page 21 Handling Functionality of the water level increase The water level increase functions as follows: The water level increase is switched off when the rotatable rosette is pulled out. The water drains via the drain hole behind the rotatable rosette. The water level increase is switched on when the rotatable rosette is pushed in.
-
Page 22: Care
Handling Deactivating water level increase There are two methods of deactivating the water level increase: Pull out the rotatable rosette. Turn the rotatable rosette to the left. ð The water level increase is switched off. Care NOTICE! Risk of damage due to unsuitable cleaning agent. The following cleaning agents can damage chrome-plated surfaces and therefore may not be used: –...
