S U B - Z E R O B U I LT- I N
I C E | WAT E R D I S P E N S I N G M O D E L S
I C E | W AT E R D I S P E N S E R
For Models 685 and 695, the automatic ice and
water dispenser gives you both ice and chilled
water without having to open doors.
Limit continuous ice and/or water
dispenser operation to seven minutes or
less, to avoid damaging the equipment.
I C E D I S P E N S E R O P E R AT I O N
To operate the ice dispenser for Models 685
and 695, set a glass on the water grille of the
glasswell, and press and hold the ICE key pad
on the glasswell until you have the ice you
need. For larger quantities of ice, open the
refrigerator door and place an ice container
under the dispenser chute, then press the
BULK ICE key pad on the Control Center.
Refer to the illustrations below.
After initial ice maker start-up, discard the first
few batches of ice—they may be discolored by
the new system plumbing.
Key Pad
Water
Key Pad
Lock
Indicator
Light
Touch Pad
Key Pad
Water
Grille
Glasswell
Bezel
Glasswell – Models 685 and 695
U S E & C A R E
Ice
Freezer
Control
Ice
On/Off
Unit
On/Off
Bulk ice dispenser –
Models 685 and 695
Use a sturdy glass to catch ice crescents.
Fragile glasses can break. Also, to avoid
breakage, make sure that the glass is
sitting vertically on the water grille.
W AT E R D I S P E N S E R O P E R A T I O N
To operate the water dispenser for Models 685
and 695, set a glass on the water grille of the
glasswell, and press and hold the WATER key
pad on the glasswell until the glass is filled.
The first time you use the water dispenser,
purge the water system and storage tank for
three minutes. This will clear out any air in the
system, along with foreign material in the new
plumbing connection.
Initially, for water to dispense properly, the
WATER key pad must be depressed and held
until water flows from the dispenser. You may
have to hold the key pad for 60 seconds for
water to fill the internal reservoir tank.
IMPORTANT NOTE: The chilled water reser-
voir tank is mounted inside the refrigerator
section. It will take several hours to chill the
water to the refrigerator temperature during
the original fill or after a lot of water is used.
REFRIGERATOR
COLDER
Refrigerator
WARMER
Control
FREEZER
COLDER
WARMER
ICE
Bell
ON/OFF
On/Off
ON/OFF
UNIT
Bulk Ice
ON/OFF
BULK ICE
Dispenser
DISPENSER
