S U B - Z E R O B U I LT- I N
D O O R S H E LV E S A N D D A I RY
C O M P A R T M E N T
The door shelves and dairy compartment are
adjustable within the guides of the door liner.
NOTE: Glass door models do not have door
shelves or a dairy compartment.
To remove a shelf or the dairy compartment,
lift it up and out from the bottom. To reinstall,
push it down into the guides. Refer to the
illustration below.
Door shelf removal
U S E & C A R E
Freezer basket removal – Models
601F, 661, 642, 685, 632 and 695
F R E E Z E R S T O R A G E
F R E E Z E R B A S K E T R E M O V A L
Models 601F, 661, 642, 685, 632 and 695:
First, unload the freezer basket. To remove
the basket, pull it out until it stops. Raise the
front of the basket and pull it out. Refer to the
illustration below.
If the door is limited to a 90-degree opening,
pivot the basket away from the door and tilt it
up sharply as soon as the rollers leave the
tracks. If the basket sticks during removal, lift it
up to disengage the rollers. To reinstall the
basket, reverse the procedure.
Models 611, 611G, 650 and 650G: First,
unload the freezer baskets. To remove the
upper freezer basket, lift up on the front and
pull forward to release the basket. To remove
the lower freezer basket, lift the basket directly
upward and out. Refer to the illustration below.
To reinstall the lower freezer basket, insert the
basket into the four corner retainers. To rein-
stall the upper freezer basket, position the
basket onto the slide rails. Slide the basket
towards the back. You should hear an audible
click when the engagement is made.
IMPORTANT NOTE: Unload the freezer
baskets before removing.
Freezer basket removal –
Models 611, 611G, 650 and 650G
