4.2 Display

Figure 6 Digital hotplate model
Characters Descriptions
Temperature When heating function was switched ON,
display area LED displays the temperature setting
value and shifts to real value in 5 seconds.
When the heating function is switched
OFF and the hotplate temperature is still
above 50°C, LED
otherwise LED displays OFF.
Speed display When stirring function was switched ON,
area LED displays the speed setting value and
flashes. The setting value does not flash
until real speed reaches the set point.
Table 3
Characters
Speed display
area
displays "Hot",
7
Figure 7 Digital model
Descriptions
When stirring function was switched
ON, LED displays the speed setting
value and flashes. The setting value
does not flash until real speed reaches
the set point.
Table 4
