MS-(H)-Pro Digital （ Hotplate） Magnetic Stirrer
Cat No.12300137
MS-H-Pro
Digital Hotplate Magnetic Stirrer
MS-Pro
Digital Magnetic Stirrer
Please read the User Manual and the related Video of this
instrument on our website carefully before use, and follow
all operating and safety instructions!
The website www.scilogex.com
User Manual
Advertisement
Table of Contents
Related Manuals for Scilogex MS-H-Pro
Summary of Contents for Scilogex MS-H-Pro
- Page 1 User Manual MS-H-Pro Digital Hotplate Magnetic Stirrer MS-Pro Digital Magnetic Stirrer Please read the User Manual and the related Video of this instrument on our website carefully before use, and follow all operating and safety instructions! The website www.scilogex.com Cat No.12300137...
-
Page 3: Table Of Contents
5.1 Control Elements 5.2 Display 6 Initialization 6.1 Initializing Sequence 6.2 Default Settings 6.3 Resetting Parameters to Factory Settings 7 Operating Modes 7.1 Operation Mode of MS-H-Pro 7.2 Operation Mode of MS-Pro 8 Function: Heating(MS-H-Pro) 8.1 Working with External Temperature Sensor... -
Page 4: Preface
Warranty Service You have purchased a Scilogex instrument. This instrument When help needed, you can always contact the Sevice Department is warranted to be free from defects in materials and... -
Page 5: Safety Instructions
MS-(H)-Pro Digital（Hotplate）Magnetic Stirrer clean, non-slip, dry and fireproof surface, do not operate 1 Safety Instructions the instrument in explosive atmospheres, with hazardous substances or under water. • Gradually increase the speed, reduce the speed if : The stirring bar breakaway because of too high speed The instrument is not running smoothly, or container moves on the base plate. -
Page 6: Proper Use
MS-(H)-Pro Digital（Hotplate）Magnetic Stirrer components. Safe operation is only guaranteed with the (min. 100 mm). accessories described in the “Accessories” chapter. Accessories must be securely attached to the device and cannot come off by themselves. Always disconnect the plug before fitting accessories. >100mm •... -
Page 7: Inspection
MS-(H)-Pro Digital（Hotplate）Magnetic Stirrer • Ensure the power be off 3 Inspection • Plug in the power cable，ensure the power be on and begin initializing. 3.1 Receiving Inspection • Add the medium into the vessel with a stirring bar. • Put the vessel on the workplate. Unpack the equipment carefully and check for any damages •... -
Page 8: Control And Display
“Stirring” is switched ON or OFF via 5.1 Control elements Stir push the knob. LED Heat Temperature control Set the rated temperature. The function (MS-H-Pro) knob “heating” is switched ON or OFF via Mode Key Heat push the knob. (MS-H-Pro) -
Page 9: Display
MS-(H)-Pro Digital（Hotplate）Magnetic Stirrer 5.2 Display Note: If both heating and stirring functions have been Real value Temperature Stir started at the same time, the display of function Temp Stir “heating” always has higher priority. If in this ℃ Error case speed is changed via the stirring knob, it Rated value display stirring speed and reverses to temperature... -
Page 10: Resetting Parameters To Factory Settings
Table 4 Operation mode C 6.3 Resetting parameters to factory settings MS-H-Pro maintains the state of the heating and stirring Reset the parameters to the default settings, as follows: ● functions before the last switching off (mains OFF), as well •... -
Page 11: Function: Heating(Ms-H-Pro)
8.1 Working with external temperature sensor 8 Function: Heating(MS-H-Pro) The device is controlled by Digital Temperature Control Technology ,which has two separate safe circuit. The hotplate is kept at a constant temperature by a digital control circuit. -
Page 12: Residual Heat Warning（Hot
MS-(H)-Pro Digital（Hotplate）Magnetic Stirrer In the B mode, if the external temperature sensor is not In order to prevent the risk of burns from a hotplate, MS-H- plugged in, “Probe” will flash. If plugged in, “Probe” Pro has a residual heat warning function. When the heating will be shown on the digital display to indicate that the function is switched off and the hotplate temperature is sensor is operating. -
Page 13: Function: Stirring
MS-(H)-Pro Digital（Hotplate）Magnetic Stirrer set. 9 Function: Stirring Breakaway can occur when stirring at high speeds , when large stirring bars are being driven at speeds close to the 9.1 Basic Stirring maximum magnetically torque or sample viscosity changes. Using MS-(H)-Pro, stirring bar breakaway monitoring The function “stirring”... -
Page 14: Remote Control
MS-(H)-Pro Digital（Hotplate）Magnetic Stirrer in start-stop-operation. 10 Remote control • Mode of transmission: Fully Duplex. • 1 start bit; 7 character bits; 1 parity bit [straight (even]); 1 stop bit. • Transmission speed: 9600 bit/s NOTE: Forbid to plug in or plug out the RS 232C communication line! 11 Faults Figure 6... -
Page 15: Maintenance And Cleaning
MS-(H)-Pro Digital（Hotplate）Magnetic Stirrer • Heating cannot be started when push the temperature Dyes Isopropyl alcohol control knob, or stirring cannot be started when push the Water containing tenside / Construction materials speed control knob. isopropyl alcohol - Check whether the unit is in the mode setting program, Water containing tenside / Cosmetics Exit from the mode setting and restart the heating/... -
Page 16: Associated Standards And Regulations
Stainless steel/porcelain enamel Instrument guidelines: 73/023/EWG Ø of the hotplate [mm] Ø 135 Heating power[W] 500(MS-H-Pro) 14 Technical data Heating rate (1L water) [K/min] 6(MS-H-Pro) Temperature range [℃] RT~340(MS-H-Pro) Temperature display[℃] LCD(MS-H-Pro) Voltage [VAC] 200-240 / 100-120 Temperature display accuracy [℃] 0.1(MS-H-Pro) -
Page 17: Products Andaccessories
The safety temperature range MS-H-Pro Digital Hotplate Magnetic 100~350(MS-H-Pro) of the hotplate [℃] 811123029999 Stirrer ，Porcelain enamel,USA plug, 110V/50Hz/60Hz Temperature sensor in medium PT1000(MS-H-Pro) MS-H-Pro Digital Hotplate Magnetic Control accuracy of heating 811123039999 Stirrer ，Stainless Steel, Cn plug, temperature with temperature 0.2(MS-H-Pro) 220/50Hz/60Hz sensor [℃]... - Page 18 Stirring bars（80mm x 13mm），1pcs/pk MS-Pro Digital Magnetic Stirrer ，Stainless 811113049999 18900015 Stirring bar mover，1pc Steel，UK plug, 220V/50Hz/60Hz 18900016 PT1000 Tempersture probe for MS-H-pro MS-Pro Digital Magnetic Stirrer ，Stainless 811113089999 18900017 Stander kit of PT1000 Steel，USA plug, 220V/50Hz/60Hz F100 unit cover，for none heat plate...
-
Page 19: Main Spare Parts
MS-(H)-Pro Digital（Hotplate）Magnetic Stirrer 16.2 List of spare parts 16 Main spare parts 16.1 Spare parts diagram Name Name Workplate Driver circuit board Hole for external Direct-current Motor temperature without brush sensor holder Mains switch Turntable Internal temperature Housing sensors Ventilation Permanent magnet Control panel Heating parts... - Page 20 SCILOGEX, LLC 500 Four Rod Road Suite 122 Berlin, CT 06037 Tel：1- (860) 828-5614 Fax：1- (860) 828-5389 E-mail: info@scilogex.com Website：Http://www.scilogex.com...
