UM11099
PCAL6534 demonstration board OM13541
Rev. 1.0 — 1 August 2019
Document information
Information
Content
Keywords
OM13320 Fm+ development kit, OM13260 Fm+ I2C bus development board,
OM13303 GPIO target board
Abstract
Installation guide and User Manual for the OM13541 34-bit GPIO Daughter
Card that connects to OM13260 Fm+ I2C bus development board. This
daughter board makes it easy to test and design with the PCAL6534, an ultra-
low voltage translating 34-bit general purpose I/O expander that provides
remote I/O expansion for most microcontroller families via the Fast-mode
Plus (Fm+) I2C-bus interface. This daughter board, along with the Fm+
Development board, provides an easy to use evaluation platform.
User manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OM13541 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NXP Semiconductors OM13541

Summary of Contents for NXP Semiconductors OM13541

  • Page 1 OM13303 GPIO target board Abstract Installation guide and User Manual for the OM13541 34-bit GPIO Daughter Card that connects to OM13260 Fm+ I2C bus development board. This daughter board makes it easy to test and design with the PCAL6534, an ultra-...

  • Page 2: Revision History

    UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Revision history Date Description 20190801 Initial version UM11099 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2019. All rights reserved. User manual Rev. 1.0 — 1 August 2019...

  • Page 3: Introduction

    UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Introduction The PCAL6534 34-bit GPIO evaluation board allows bidirectional voltage-level translation and GPIO expansion between 0.8 V to 3.6 V on SCL/SDA and 1.8 V, 2.5 V, 3.3 V, 5.5 V on I/O ports with active low reset input control and open-drain active low interrupt output indicator (red LED) plus one hardware address input setting to select one of four different slave addresses.

  • Page 4: Features Of The Om13541 34-Bit Gpio Daughter Board

    UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Features of the OM13541 34-bit GPIO daughter board • Direct connection to OM13260 Fm+ I C-bus Development board • Easy to use GUI-based software demonstrates the capabilities of the PCAL6534 • Jumper configuration for most features of PCAL6534 •...

  • Page 5: Hardware Description

    Hardware description 3.1 Power supply jumpers The power supply selection for the OM13541 is very flexible and allows for detailed analysis and evaluation of 34-bit GPIO device. J13 selects +5V_PWR supply from either the tester connector J1 (pins 4 and 6, +5V_TSTR) or the Fm+ board connector J11 (pins 7 and 12, +5V).

  • Page 6: Connector Pinouts

    UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 3.5 Connector pinouts • J1 (10-pin male tester connector) is connected to master which is driving either I bus for PCAL6534. This is easily achieved with third party development tools from Total Phase (http://www.totalphase.com). There are two tools called Aardvark and Beagle that direct connect to this board through J1.

  • Page 7: All Jumpers Default Setting And Test Points

    UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 when the voltage is above VDDP x 0.7V. The LEDs remain off when the voltage is between those two levels. Table 3. J12, J13, J14, J15, J16 10-pin GPIO target board connector J[12:16] pin #...
  • Page 8 1-2: select external oscillator (EXT_OSC) input for debounce circuit use 2-3: select P2_0 input as normal operation 1. Default PCAL6534 slave address is set to 0x46 (ADDR = VDD) Figure 2. PCAL6534 demo board (OM13541) UM11099 All information provided in this document is subject to legal disclaimers.
  • Page 9 UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Figure 3. PCAL6534 demo board (OM13541) detailed UM11099 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2019. All rights reserved. User manual Rev. 1.0 — 1 August 2019...

  • Page 10: Schematic

    UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Schematic Figure 4. PCAL6534 demo board schematic UM11099 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2019. All rights reserved. User manual Rev. 1.0 — 1 August 2019...

  • Page 11: Installation

    Installation 5.1 PCAL6534 demo board, Fm+ development board, GPIO target board The OM13541 PCAL6534 34-bit GPIO demo board is a daughter card to the OM13260 Fm+ I2C bus development board, which is part of the Fm+ development board kit (OM13320); three I/O ports (8-bit × 3) on PCAL6534 are connected to the GPIO target board for I/O visualization.

  • Page 12: Pcal6534 Evaluation Steps With Fm+ Development Board

    UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 PCAL6534 evaluation steps with Fm+ development board The PCAL6534 is controlled by the Fm+ development board GUI in Expert mode as shown in Figure 6 Figure Figure 6. Select the Expert Mode from Fm+ development board GUI (1 of 2) UM11099 All information provided in this document is subject to legal disclaimers.

  • Page 13: Pcal6534 Output Shifting Pattern Demo For All Five Ports

    UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Figure 7. Select the Expert Mode from Fm+ development board GUI (2 of 2) Connect the hardware as described in Section 5.2. All jumpers are in default setting and device address is set to 0x46h on J8 (set ADDR = VDDI) for PCAL6534 demo board.

  • Page 14: Pcal6534 Registers Are Controlled By Fm+ Board Gui

    UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 46,Write,Yes,200,05,FB,FB,FB,FB,Comments: set bit2 to 0 in Ports 0 to 3 46,Write,Yes,200,05,F7,F7,F7,F7,Comments: set bit3 to 0 in Ports 0 to 3 46,Write,Yes,200,05,EF,EF,EF,EF,Comments: set bit4 to 0 in Ports 0 to 3 46,Write,Yes,200,05,DF,DF,DF,DF,Comments: set bit5 to 0 in Ports 0 to 3...
  • Page 15 UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Figure 9. Device selection screen for PCAL6534 2. Input registers read are shown in Figure Figure 10. Device configuration screen for registers 00-04 hex 3. Output registers read or write are shown in Figure UM11099 All information provided in this document is subject to legal disclaimers.
  • Page 16 UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Figure 11. Device configuration screen for registers 05-09 hex 4. Polarity registers read or write are shown in Figure Figure 12. Device configuration screen for registers 0A-0E hex 5. Port Configuration registers read or write are shown in...
  • Page 17 UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Figure 13. Device configuration screen for registers 0F-13 hex 6. Drive strength registers read or write are shown in Figure Figure 14. Device configuration screen for registers 30-38 hex 7. Input latch registers read or write are shown in...
  • Page 18 UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Figure 15. Device configuration screen for registers 3A-3E hex 8. PU/PD Enable registers read or write are shown in Figure Figure 16. Device configuration screen for registers 3F-43 hex 9. PU/PD select registers read or write are shown in...
  • Page 19 UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Figure 17. Device configuration screen for registers 44-48 hex 10.Interrupt mask registers read or write are shown in Figure Figure 18. Device configuration screen for registers 49-4D hex 11.Output port configuration register read or write is shown in...
  • Page 20 UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Figure 19. Device configuration screen for registers 53 hex 12.Interrupt edge registers read or write are shown in Figure Figure 20. Device configuration screen for registers 54-5C hex 13.Interrupt Clear registers write are shown in...
  • Page 21 UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Figure 21. Device configuration screen for registers 5E-62 hex 14.Input status registers read are shown in Figure Figure 22. Device configuration screen for registers 63-67 hex 15.Pin Configuration registers read or write are shown in...
  • Page 22 UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Figure 23. Device configuration screen for registers 68-6C hex 16.Debounce registers read or write are shown in Figure Figure 24. Device configuration screen for registers 6D-6F hex UM11099 All information provided in this document is subject to legal disclaimers.

  • Page 23: Support

    UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Support For support, please send an E-mail to: i2c.support@nxp.com UM11099 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2019. All rights reserved. User manual Rev. 1.0 — 1 August 2019...

  • Page 24: Abbreviations

    UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Abbreviations Table 5. Abbreviations Acronym Description Electro Static Discharge GPIO General Purpose Input/Output Graphical User Interface C-bus Inter-integrated Circuit bus Light Emitting Diode Personal Computer Printed-Circuit Board SMBus System Management Bus Universal Serial Bus UM11099 All information provided in this document is subject to legal disclaimers.

  • Page 25: References

    1. PCAL6534, Ultra low-voltage translating 34-bit Fm+ I C-bus/SMBus I/O expander; Product data sheet; NXP Semiconductors 2. UM10741, Fm+ Development Kit OM13320 User manual; NXP Semiconductors UM11099 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2019. All rights reserved.

  • Page 26: Legal Information

    Customer is responsible for doing all necessary testing for the customer’s applications and products using NXP Semiconductors products in order to avoid a 10.2 Disclaimers default of the applications and the products or of the application or use by customer’s third party customer(s).
  • Page 27 UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Tables Tab. 1. J1 10-pin tester connector ........ 6 Tab. 4. All jumpers setting for test and evaluation ..7 Tab. 2. J11 18-pin Fm+ board connector ...... 6 Tab. 5. Abbreviations ...........24 Tab. 3.
  • Page 28 Device configuration screen for registers Fig. 2. PCAL6534 demo board (OM13541) ....8 30-38 hex ............17 Fig. 3. PCAL6534 demo board (OM13541) detailed ..9 Fig. 15. Device configuration screen for registers Fig. 4. PCAL6534 demo board schematic ....10 3A-3E hex ............18 Fig.

  • Page 29: Table Of Contents

    UM11099 NXP Semiconductors PCAL6534 demonstration board OM13541 Contents Introduction ............3 Features of the OM13541 34-bit GPIO daughter board ............4 Hardware description ......... 5 Power supply jumpers ........5 SCL and SDA jumpers ........5 Device reset, interrupt and address pin selection .............5...
