7.2

Unfolding the wheelchair

To unfold the wheelchair, please follow the following operations:
• Attach the rear wheels of the wheelchair to frame by the quick-release system. By meaning of pressing the
black button (photo 43), you can attach the rear wheels to the wheelchair (photo 44);
• Go stand next to the wheelchair and push on the two seat tubes down to fold the wheelchair;
• To make sure the wheelchair is folded correctly, push both of the seat tubes as far as possible outside (photo
46). You can also see if the wheelchair is folded correctly, by the upholstery;
• You can now place the legrests back on the wheelchair. You can do this by placing the leg supports to the side
(photo 47) and then push in the correct position by turning inward. The legrests will then engage himself. This
click you will hear is the confirmation that the legrests are placed on the correct way (see photo 48);
• Finally, place the seat cushion if your wheelchair is equipped with one. The wheelchair is now ready for use.
If the wheelchair is folded in your car, you should make sure that the wheelchair remains in place. You can do this
by attaching the wheelchair. This include taxi fixation points available on the wheelchair.
EXCEL G-EVOLUTION | PHOTO 43
EXCEL G-EVOLUTION | PHOTO 47
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
User manual | Excel G-Evolution
EXCEL G-EVOLUTION | PHOTO 44
EXCEL G-EVOLUTION | PHOTO 48
© 2015 Excel, part of Van Os Medical B.V.
EXCEL G-EVOLUTION | PHOTO 45
25
EXCEL G-EVOLUTION | PHOTO 46
