6.6

The legrests

The legrests of the Excel G-Evolution are both foldable and removable. To swing the legrests away and take them
off, you should follow the steps described below.
• The legrests of the wheelchair are shown on photo 20;
• By pulling the black lever (photo 21) up (picture 22), the leg supports can come in motion;
• In photo 23 you can see the legrests can be turned away;
• If you want to take off the leg rests, you can pull up the leg rests. This can be done when the legrests can not
be further folded;
• The legrest is released when it is past the elevations which sit on the side of the frame;
• To place the legrests you put the legrests over the increases who are on the side of the frame and then turn
the legrests in place until you hear a click. This click confirms that the legrests are mounted properly.
EXCEL G-EVOLUTION | PHOTO 20
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
User manual | Excel G-Evolution
EXCEL G-EVOLUTION | PHOTO 21
© 2015 Excel, part of Van Os Medical B.V.
EXCEL G-EVOLUTION | PHOTO 22
20
EXCEL G-EVOLUTION | PHOTO 23
