6. Components of the Excel G-
In this chapter the different components of the Excel G-Evolution are described. On the wheelchair are a number
of components present which are adjustable. If you want to add or remove any of its components, make any
adjustments of replace components, you should always follow the instructions described in this user manual.
6.1

Fold and unfold the wheelchair

To fold or unfold the wheelchair, there are some steps you should follow. When folding and unfolding the
wheelchair you should always be careful so that the wheelchair does not get damaged.
6.1.1

Folding the wheelchair

If you want to fold the wheelchair, please follow the following steps.
• Before you can fold the wheelchair, the footrests should be raised. On photo 1 you can see how the footrests
are like when the wheelchair is unfolded. By folding the foot rests upwards (photo 2), you can fold the
wheelchair. On photo 3 you see the wheelchair when the footrests are folded upwards;
• To fold the wheelchair, you need to follow the operation as you can see on photo 4. You pull at the front and
at the back of the seat, at the middle of the seat of the wheelchair;
• Now you can pull the middle of the seat, on both the front and the back, as shown in photo 5;
• After the seat is completely pulled up, the chair looks like shown on photo 6.
EXCEL G-EVOLUTION | PHOTO 1
EXCEL G-EVOLUTION | PHOTO 5
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
User manual | Excel G-Evolution
EXCEL G-EVOLUTION | PHOTO 2
EXCEL G-EVOLUTION | PHOTO 6
© 2015 Excel, part of Van Os Medical B.V.
Evolution
EXCEL G-EVOLUTION | PHOTO 3
16
EXCEL G-EVOLUTION | PHOTO 4
