6.7

The footplates

At the legrests are also footplates attached. These are both foldable and adjustable in height.
6.7.1

Folding the footplates upwards

You can fold the footplates by following the following steps.
• At photo 24 you see how the wheelchair looks like when the footplates are not folded;
• You can fold the footrests by pushing the footplates simply upwards, as shown in photo 25;
• In photo 26 you can see how the footplates look like when the they are folded.
EXCEL G-EVOLUTION | PHOTO 24
6.7.2

Adjust the height of the footplates

It is also possible to adjust the height of the footplates. As you can see on picture 27, the footplates are adjustable
in five different heights. To adjust the height, you need an allen key.
6.8

The frame

The frame of the Excel G-Evolution is based on the coating principle. This means the frame is extra firm.
Furthermore, the wheelchair is provided with a cross-frame. This also provides additional rigidity to the wheelchair.
The cross frame is shown on to photo 28.
EXCEL G-EVOLUTION | PHOTO 28
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
User manual | Excel G-Evolution
EXCEL G-EVOLUTION | PHOTO 25
© 2015 Excel, part of Van Os Medical B.V.
EXCEL G-EVOLUTION | PHOTO 26
21
EXCEL G-EVOLUTION | PHOTO 27
