  • Page 1 Product documentation Last edited: 25/03/2019 Alarm control unit Connect Order No. 5201 00...
  • Page 2: Table Of Contents

    4.1. Configuring KNX devices......................9 4.2. Example of use .......................... 10 4.2.1.KNX connection ........................10 4.2.2.Secure remote access with Gira S1 ..................11 4.3. KNX functions..........................11 4.4. Topology ............................ 12 4.4.1.Alarm control unit Connect in main line ................12 4.4.2.Alarm control unit Connect in area line ................
  • Page 3: About The Product

    IP (address range from 169.254.1.0 to 169.254.254.255) is issued after a certain waiting time. You can also issue a static IP address via the ETS or the Gira Project Assistant. You can set IP address, IP subnet mask and IP standard gateway here.
  • Page 4: Technical Data

    Dimensions of housing (H x W x D): 285 x 170 x 30 mm (without adapter frame) Dimensions of housing (H x W x D): 285 x 170 x 46 mm (with adapter frame) Order No. 5201 00 Page 4...
  • Page 5: Safety Notes

    Do not open the device housing. Always observe the device’s technical specifications. This product contains a rechargeable battery. Keep new and used batteries away from children. These instructions are part of the product and must remain with the end customer. Order No. 5201 00 Page 5...
  • Page 6: Installation And Electrical Connection

    Position 2 Position 1 When the hinged cover is open, all connections (battery Position 0 pack, LAN, telephone, etc.) and the mounting holes are accessible. Order No. 5201 00 Page 6...
  • Page 7: Installation

    Make sure the wall surface is level. In the case of an uneven wall surface, there is the possibility that the housing will move during installation. This can cause the housing cover to be improperly inserted and closed. Order No. 5201 00 Page 7...
  • Page 8 3. Configure the project in the GPA and transfer it to the alarm centre memory (also see the enclosed Quick Start Guide). 4. Close the hinged cover on the battery compartment and tighten the two screws. Leave the housing cover off and stay in configuration mode. Order No. 5201 00 Page 8...
  • Page 9: Configuring Knx Functions

    • In ETS 5, select Options under the Bus tile and check whether Use direct IP connection if available is activated. This will make transmission of the KNX configuration from the ETS to the alarm control unit Connect faster. Order No. 5201 00 Page 9...
  • Page 10: Example Of Use

    Configuring KNX functions 4.2. Application example 4.2.1. KNX connection The Gira Alarm Connect security system with Gira G1 alarm client and smartphone app to act as addi- tional operating and display devices. Connected to KNX via KNX IP router. Router...
  • Page 11: Secure Remote Access With Gira S1

    4.2.2. Secure remote access with the Gira S1 The Gira S1 is installed in the customer's home network and prepares the home network for secure access via the Internet. It connects to the Gira device portal automatically using the existing Internet access.
  • Page 12: Topology

    4.4.1. Alarm control unit Connect in main line The following topology illustrates how the alarm control unit Connect is operated in the main line together with the Gira G1. in this case the KNX IP router is used as a line coupler. Alarm control...
  • Page 13 Configuring KNX functions When installing the alarm control unit Connect in the main line, the configuration in ETS 5 would be as follows: ETS 5 screenshot: Alarm control unit Connect in main line Order No. 5201 00 Page 13...
  • Page 14: Alarm Control Unit Connect In Area Line

    The following topology illustrates how the alarm control unit Connect is operated in the area line together with the Gira G1. In this case the KNX IP router is used as an area coupler and the area/line coupler is used as a line coupler.
  • Page 15 Configuring KNX functions When installing the alarm control unit Connect in the area line, the configuration in ETS 5 would be as follows: Topology example: Alarm control unit Connect in area line Order No. 5201 00 Page 15...
  • Page 16: Starting Up

    From mask version: 57b0 5.1. ETS configuration and start-up Configuring and starting up the alarm control unit Connect requires ETS 5 or higher and the Gira Pro- ject Assistant (version 4 or higher). The required product database is available in *.knxprod format.
  • Page 17: External Detectors

    If you activate this option, you will also need to activate the alarms that you want the external detec- tors in this security area to trigger. The KNX communication objects can only trigger an event in the ETS application if the corresponding alarms have been activated in the GPA. Order No. 5201 00 Page 17...
  • Page 18 Use KNX communication objects option has been deliberately activated in the project configuration. • The alarms’ data points are always shown in the data point view but only perform a function if the corresponding alarm has been set here, too. Order No. 5201 00 Page 18...
  • Page 19: Programming Physical Address And Application Software

    Important: When you open the housing cover, a tamper alarm triggers. • Use the Gira Project Assistant (version 4 or higher) to start programming mode. The alarm control unit Connect does not have a programming button or programming LED.
  • Page 20 5. Open KNX programming mode. 6. Enter value 1 and hit enter to confirm. Programming mode activates. 7. Program the physical address using the ETS. 8. Note the physical address on the alarm control unit Connect’s hinged cover. Order No. 5201 00 Page 20...
  • Page 21: Software

    IP (address range from 169.254.1.0 to 169.254.254.255) is issued after a certain waiting time. You can also issue a static IP address via the ETS or the Gira Project Assistant. You can set IP address, IP subnet mask and IP standard gateway here.
  • Page 22: Object Table

    1 bit 1.001 switching C, W mode Show KNX alarm communication objects: Active. Object for receiving the programming mode. "1" means that programming mode is activated, and "0" means that programming mode is deactivated. Order No. 5201 00 Page 22...
  • Page 23 C, R, T 1202, area 2, devices arm- 1302, security area 3, ing ready 1402 security area 4 Objects for reading whether the entry components are ready. “1” means ready, “0” means not ready. Order No. 5201 00 Page 23...
  • Page 24 C, R, T 1224, area 2, externally 1324, security area 3, armed status 1424 security area 4 Object for reading whether a burglar alarm (externally armed) has been triggered. “1” means yes, “0” means no. Order No. 5201 00 Page 24...
  • Page 25 Main security area, security Presence 1 bit 1.017 trigger C, W 1234, area 2, detection 1334, security area 3, 1434 security area 4 Object for writing presence detection. “1” or “0” means presence detected. Order No. 5201 00 Page 25...
  • Page 26 3, 1440 security area 4 Object for reading whether or not a monitoring alarm has been triggered (one of the security system’s components is not responding). “1” means yes, “0” means no. Order No. 5201 00 Page 26...
  • Page 27 Main security area, security Door chime 1 bit 1.016 confirma- C, T 1281, area 2, tion 1381, security area 3, 1481 security area 4 Sends “1” when the door chime is actuated. “0” no action. Order No. 5201 00 Page 27...
  • Page 28: Parameters

    7.2. Main security area, security area 2, security area 3, security area 4 Parameters Entry / Selection Remarks Show KNX alarm com- Checkbox (inactive) The communication objects for triggering an alarm munication objects are available. Order No. 5201 00 Page 28...
  • Page 29 Giersiepen GmbH & Co. KG Electrical installation systems Industriegebiet Mermbach Dahlienstrasse 42477 Radevormwald, Germany PO Box 12 20 42461 Radevormwald Germany Tel +49(0)21 95 - 602-0 Fax +49(0)21 95 - 602 -191 www.gira.de info@gira.com Order No. 5201 00 Page 29...
