System 3000
Blind control insert with auxiliary input
Blind control insert with auxiliary input
Order no.: 5414 00
Operating instructions
1

Safety instructions

Electrical devices may only be mounted and connected by electrically skilled persons.
Serious injuries, fire or property damage possible. Please read and follow manual fully.
Danger of electric shock. Always disconnect before carrying out work on the devise or load. In
so doing, take all the circuit breakers into account, which support dangerous voltages to the
device and or load.
Danger of electric shock. Do not mount the device on unearthed, electrically conductive sub-
strates or let it come into contact with them.
Risk of injury. Use the device only for controlling Venetian blind and roller shutter motors or
awnings. Do not use it to switch other loads.
For parallel connection of several motors to an output it is essential to observe the correspond-
ing instructions of the manufacturers, and to use a cut-off relay if necessary. The motors may be
destroyed.
Use only venetian blind motors with mechanical or electronic limit switches. Check the limit
switches for correct adjustment. Observe the specifications of the motor manufacturers. Device
can be damaged.
These instructions are an integral part of the product, and must remain with the end customer.
2
Device components
(1)
Venetian blind insert
(2)
Frame
(3)
Cover
(4)
Terminals
(5)
Button TEST
82595612
Figure 1: Device components
06.03.2019
1 / 6

Advertisement

loading

Related Manuals for Gira System 3000

Summary of Contents for Gira System 3000

  • Page 1: Safety Instructions

    System 3000 Blind control insert with auxiliary input Blind control insert with auxiliary input Order no.: 5414 00 Operating instructions Safety instructions Electrical devices may only be mounted and connected by electrically skilled persons. Serious injuries, fire or property damage possible. Please read and follow manual fully.

  • Page 2: Intended Use

    System 3000 Blind control insert with auxiliary input Intended use – Controlling electrically driven blinds, rolling shutters and awnings – Automatic time controller using the cover or extension inputs – Operation only with suitable cover – Mounting in appliance box according to DIN 49073 Product characteristics –...
  • Page 3 System 3000 Blind control insert with auxiliary input Connecting and mounting venetian blind insert Figure 2: Control with extension Figure 3: Terminal-specific cable cross-section: ￭ Connecting venetian blind insert (1) (Figure 2). Note clampable cable cross-sections (Figure 3). Optional: Connection of an extension (6). A mechanical venetian blind push- button or venetian blind switch can also be used as an extension instead of the venetian blind insert.
  • Page 4 System 3000 Blind control insert with auxiliary input Integrating the device into a group control The venetian blind insert can be integrated into a group control (Figure 4), either for local control (1) or as a master unit (7). Figure 4: Connection example of group control ￭...

  • Page 5: Technical Data

    The warranty is provided in accordance with statutory requirements via the specialist trade. Please submit or send faulty devices postage paid together with an error description to your re- sponsible salesperson (specialist trade/installation company/electrical specialist trade). They will forward the devices to the Gira Service Center. 82595612 06.03.2019...
  • Page 6 System 3000 Blind control insert with auxiliary input Gira Giersiepen GmbH & Co. KG Elektro-Installations- Systeme Industriegebiet Mermbach Dahlienstraße 42477 Radevormwald Postfach 12 20 42461 Radevormwald Deutschland Tel +49(0)21 95 - 602-0 Fax +49(0)21 95 - 602-191 www.gira.de info@gira.de 82595612 06.03.2019...
