Gira System 3000 User Manual

Blind timer and timer display
Hide thumbs Also See for System 3000:

Advertisement

Quick Links

Download this manual
System 3000
Blind timer and timer Display
Blind timer and timer Display
Order no.: 5366 ..
User manual
1

Safety instructions

Electrical devices may only be mounted and connected by electrically skilled persons.
Serious injuries, fire or property damage possible. Please read and follow manual fully.
Danger of electric shock. Always disconnect before carrying out work on the devise or load. In
so doing, take all the circuit breakers into account, which support dangerous voltages to the
device and or load.
These instructions are an integral part of the product, and must remain with the end customer.
2
Device components
(1)
active functions
(2)
Time of the next action or current time of day
(3)
Type of the next action
(4)
Operating area
Icons in the display
The icons in the display are adjusted depending on the type of insert.
Ƙ
Automatic operation is active, next switching time is displayed for 2 minutes
ƚ
Astro function is active
Ɨ
Disabling function is active
ƞ / Ɵ
Displays the direction of the next travelling time. Flashes when controlling the
insert
OFF / ON
Displays the type of the next switching operation
Ƥ / ƥ
Displays the current switching state
Icons of the operating area (4)
Ƨ
Step back
ƨ
Confirm inputs
32596512
10865949
Figure 1: Display and operating area
10.07.2018
1 / 10

Advertisement

loading

Related Manuals for Gira System 3000

Summary of Contents for Gira System 3000

  • Page 1: Safety Instructions

    System 3000 Blind timer and timer Display Blind timer and timer Display Order no.: 5366 .. User manual Safety instructions Electrical devices may only be mounted and connected by electrically skilled persons. Serious injuries, fire or property damage possible. Please read and follow manual fully.
  • Page 2 Intended use – Manual and time-controlled operation of Venetian blinds, shutters, awnings or lighting – Operation switching, dimming or Venetian blind insert or 3-wire extension of System 3000 Product characteristics – Current time can be saved as switching time, quick programming –...
  • Page 3 System 3000 Blind timer and timer Display Commissioning Set date and time During the initial commissioning, a reset or a voltage failure of more than 4 hours, the year flashes in the display and the following data must be set.

  • Page 4: Activate Functions

    System 3000 Blind timer and timer Display Saving the ventilation position To save and execute the ventilation position, the Venetian blind/shutter must be moved to the upper end position until the flashing arrow switches off automatically. ￭ From the top end position press and hold down Ɵ.
  • Page 5 System 3000 Blind timer and timer Display In automatic operation, "next" appears in the display and the time and type of the next action is displayed. If the Astro function activated, ƚ also appears in the display. Figure 3: Manual operation In manual operation, the current time and the icon Ƙ...
  • Page 6 System 3000 Blind timer and timer Display Yes flashes in the display. ￭ Changing to No with ƞ or Ɵ deactivates the disabling function. ￭ Confirm with ƨ. The disabling function is active and the icon Ɨ appears in the display.
  • Page 7 System 3000 Blind timer and timer Display Figure 5: Default setting: Astro function for Venetian blind inserts The Astro times for Germany are shown in (Figure 5). The blind/shutter is raised at sunrise, but not before 7:00. In the evening at sunset, the blind/shutter is lowered, but not after 21:00.
  • Page 8 System 3000 Blind timer and timer Display The Astro times for Germany are shown in figure (Figure 6). As default setting for mid-week and the weekend, the lighting switches off in the morning at sunrise and switches on in the evening at sunset.

  • Page 9: Technical Data

    System 3000 Blind timer and timer Display The quick programming overwrites the existing up or down times for Venetian blind inserts. For switching and dimming inserts, the on and off times of the memory area ƙ are overwritten. Memory area Ʀ is deactivated.

  • Page 10: Warranty

    Please submit or send faulty devices postage paid together with an error description to your re- sponsible salesperson (specialist trade/installation company/electrical specialist trade). They will forward the devices to the Gira Service Center. They will forward the devices to the Gira Service Center.
