- Page 1 OW NE R’S OP ER ATION MANUAL Ra in/ Ma ins Wate r Contr o lle r I n sta lla t io n and Op e ra ting Instru ction s MOD EL: FP C-12724 MAIN ISOLATOR DOC: FPC-12724 VER 1.1...
- Page 2 Your Liquid Level Control product reflects the superior quality and attention to detail in design, engineering and manufacturing that has distinguished MATelec Products for decades. The controller incorporates the very latest in micro-processor technology, ensuring you, the owner/operator many years of functional, reliable and ‘user friendly’...
-
Page 3: Installation
Bottom Bottom C O NNECT IO N WIRING CONNECTION DETAIL FPC-12724 WORKING VALVE LEVEL PRESSURE FLOAT SWITCH SUPPLY PUMP... -
Page 4: Getting Started
G ETTI NG START ED O PERA TIONS The unique MATelec Rain/Mains Water Controller is designed to provide a continuous supply of water for a variety of uses, whilst prioritising and maximising the usage of Rain Water. The system comprises a Controller, a unique Valve and a Liquid Level Switch. The controller not only monitors the... - Page 5 FEATU RES • Unlimited pump options above ground or submersible • • No pressure reducing valves • No continuously actuated solenoid valves • Test Button - Provides change of system status, including pump and valve switching • Indicator Lights provide ‘power’, ‘valve’ and ‘fault’ status information •...
- Page 6 NOTE S...
-
Page 7: Circuit Diagram
C IRCUIT D IAGRAM 240 Vac Supply MSW1 Main Isolator TOL1 Active Neutral 240 VAC Pump Circuit Contactor 3P Breaker 2A Thermal Overload Contactor 18A 240Vac A N E E A N C NO PUMP SUPPLY ME82 FL OAT P RO BE COND. - Page 8 Mains/Town Water is in use INSTALLATION DATE: ON STEADY Either a Pump (overload) or SYSTEM FAULT a Prime Loss (if setup) Fault has occurred DISTRIBUTED BY: SERIAL NUMBER: MANUFACTURED BY MATelec AUSTRALIA EMAIL: info@matelecaustralia.com.au MATelec reserves the right to alter technical specifications without notice.
