Chapter 4 Network Address Translation (NAT
Example
The following example maps a host address to itself using an inline mapped address:
hostname(config)# object network my-host-obj1
hostname(config-network-object)# host 10.1.1.1
hostname(config-network-object)# nat (inside,outside) static 10.1.1.1
The following example maps a host address to itself using a network object:
hostname(config)# object network my-host-obj1-identity
hostname(config-network-object)# host 10.1.1.1
hostname(config-network-object)# object network my-host-obj1
hostname(config-network-object)# host 10.1.1.1
hostname(config-network-object)# nat (inside,outside) static my-host-obj1-identity
Configure Identity Twice NAT
This section describes how to configure an identity NAT rule using twice NAT.
Procedure
Step 1 Create host or range network objects (object network command), or network object groups
(object-group network command), for the source real addresses (you will typically use the same object
for the source mapped addresses), the destination real addresses, and the destination mapped addresses.
•
•
If you do create objects, consider the following guidelines:
•
•
(Optional.) Create service objects for the:
Step 2
•
•
A service object can contain both a source and destination port; however, you should specify either the
source or the destination port for both service objects. You should only specify both the source and
destination ports if your application uses a fixed source port (such as some DNS servers); but fixed
source ports are rare. For example, if you want to translate the port for the source host, then configure
the source service.
Step 3 Configure identity NAT.
nat [(real_ifc,mapped_ifc)] [line | {after-object [line]}]
source static {nw_obj nw_obj | any any}
[destination static {mapped_obj | interface [ipv6]} real_obj]
[service real_src_mapped_dest_svc_obj mapped_src_real_dest_svc_obj]
[no-proxy-arp] [route-lookup] [inactive] [description desc]
If you want to perform identity NAT for all addresses, you can skip creating an object for the source
real addresses and instead use the keywords any any in the nat command.
If you want to configure destination static interface NAT with port translation only, you can skip
adding an object for the destination mapped addresses, and instead specify the interface keyword
in the nat command.
The mapped object or group can contain a host, range, or subnet.
The real and mapped source objects must match. You can use the same object for both, or you can
create separate objects that contain the same IP addresses.
Source or Destination real ports
Source or Destination mapped ports
