I n d u s t r i a l M o t h e r b o a r d
2.4 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Label
CLRTC1
J1
J2
J3
J4
J5
2.5 List of Connectors
The board has a number of connectors that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's connectors:
Label
ATX12V
AUDIO1
BATTERY1
COM2
COM3
COM4
COM5
COM6
Function
Clear CMOS
LVDS Panel Voltage Selection
Inverter Voltage Selection
Mode Selection for Back Light Control of Inverter
AT/ATX mode Selection
COM1 Ring/+5V/+12V Selection
Function
ATX 4P Power Connector
Audio jack Connector
RTC - Coin Battery Holder
COM2 Connector
COM3 Connector
COM4 Connector
COM5 Connector
COM6 Connector
E M B - H 6 1 A
Chapter 2 Quick Installation Guide
2 - 7
