I n d u s t r i a l M o t h e r b o a r d
Options summary :
F81866 ERP Function Disabled
Enable or Disable ERP function.
Serial Port
Allows BIOS to En/Disable correspond serial port.
Device Mode
Select working model.
Change Settings
(Serial Port 1)
Allows BIOS to Select Serial Port resource.
Change Settings
(Serial Port 2)
Enabled
Disabled
Enabled
RS232
RS422
RS485
Auto
IO=3F8h; IRQ=4;
IO=3F8h; IRQ=3,4;
IO=2F8h; IRQ=3,4;
IO=3E8h;
IRQ=10,11;
IO=2E8h;
IRQ=10,11
Auto
IO=2F8h; IRQ=3;
IO=3F8h; IRQ=3,4;
IO=2F8h; IRQ=3,4;
E M B - H 6 1 A
Default
Default
Default
Default
Default
Chapter 3 AMI BIOS Setup 3-15
