2.15 1000Base-T Ethernet Connector with Dock USB 2.0 Connector
(CON17/CON18)
Pin Signal
1 +5V
3 USB2_DP2
5 +5V
7 USB2_DP1
9 LAN_CTR
11 LAN_MDI_DN0
13 LAN_MDI_DN1
15 LAN_MDI_DN2
17 LAN_MDI_DN3
19 LAN_LED_ACT
21 LAN_LED_LINK100#
23 GND
25 GND
27 GND
29 GND

2.16 Digital I/O Connector (DIO)

Pin Signal
1 DIO_I#1 (DIO_P#1)
3 DIO_I#3 (DIO_P#3)
5 DIO_O#1 (DIO_P#5)
Chapter 2 Quick Installation Guide
18
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
Pin
2
4
6
2 - 12
E M B - H 6 1 A
GND
Signal
USB2_DN2
GND
USB2_DN1
GND
LAN_MDI_DP0
LAN_MDI_DP1
LAN_MDI_DP2
LAN_MDI_DP3
GND
LAN_LED_ACT#
LAN_LED_LINK1000#
GND
GND
GND
GND
Signal
DIO_I#2 (DIO_P#2)
DIO_I#4 (DIO_P#4)
DIO_O#2 (DIO_P#6)
