Replacing a Failed Power Canister in the E5660 Controller-Drive

Tray

To access this product, go to the NetApp® Support Site at

Before you replace the power canister in the E5660 controller-drive tray, gather antistatic protection and a

replacement power canister.

ATTENTION Possible equipment damage – If you perform this procedure with the power turned on, you must

complete it within 15 minutes to prevent the possibility of overheating the equipment.

You can determine whether you have a failed power canister in two ways:

The Recovery Guru directs you to replace a failed power canister.

You locate the failed power canister by checking the Power Service Action Required LED.

Figure 1. E5660 Enclosure

1. Controller Canister

2. Power Canister

3. Fan Canister

ATTENTION Possible hardware damage – To prevent electrostatic discharge damage to the tray, use proper

antistatic protection when handling tray components.

Removing a Power Canister in the E5660 Controller-Drive Tray

1. Gather support data about your storage array by using one of these methods:

mysupport.netapp.com
