7.5 OPERATION: NOTES FOR TOUCHDOWN
The following information applies only to the TOUCHdown Handset. If you have a different Handset, pro-
ceed to the next chapter.

7.5.1 PUSH-PUSH FUNCTION

NOTICE
To avoid product damage, ensure a 10 cm Cable Loop is routed (Chapter 6.3.2, Fig. 12)
The Push-Push Function allows the TOUCHdown to be slid underneath the table when not in use, and
move outwards to the operating position when it is needed.
To move the TOUCHdown into the operation position:
1. Push the Handset towards the Table Top and release.
▸ The Handset will click when it is unlocked from its housing
2. Allow the Handset to slide out from underneath the table.
NOTICE
To avoid product damage, do not pull on the Handset while attempting to move it to
the operation position.
To stow the TOUCHdown underneath the table:
1. Lift the control panel of the Handset gently upwards until it is level with its housing.
2. Push towards the table top until the Handset clicks into position.

7.5.2 MECHANICAL RELEASE

If excessive force is applied to the Control Panel of the TOUCHdown, it will be released automatically from
its housing to prevent system damage.
To re-attach the Control Panel:
1. Align the springs on the Control Panel with the sliding mechanism of the housing.
2. Push the outer edges of the Control Panel firmly towards the housing to click it back into place.
