- Page 1 REMKO RKV 10 W / 13 W / 18 W / 24 W Multi-purpose room air conditioners Operation Technology Spare Parts REMKO – powerful like a bear. Edition GB – P05...
-
Page 3: Table Of Contents
Subject to alterations! Split-design, multi-purpose room air conditioners Wall-mounted units REMKO RKV 10 W / 13 W / 18 W / 24 W Contents Contents Page... -
Page 4: Safety Hints
à Keep in mind that it is dangerous to remove covers by authorised personnel. protective grilles, etc., during operation; this can lead to uncontrolled operating situations. à The indoor unit and the outdoor part of the REMKO air-conditioners have been technically adjusted to Transport and Packaging one another. -
Page 5: Operation
Operation 3 Swing button Two to four seconds after the indoor unit has been con- When the unit is switched on (ON), the oscillating nected to the power supply, operation can begin. blade improves air distribution of the outlet opening in the room. - Page 6 Button functionality The following commands can be performed using the remote control. Point the remote control at the receiver on the right side of the wall-mounted unit at a distance of no more than 7m. On / Off button Activate and deactivate the indoor unit with the ON / OFF button The current settings appear on the display: COOL FAN AUTO = Speed of the fan...
- Page 7 By pressing the SLEEP button, the room temperature increases by 1 °C one hour af- Sleep button SLEEP ter the function has been activated. This function can be cancelled by pressing any AUTO button. The sign disappears and the normal display appears. Functional process / any button SLEEP...
-
Page 8: System Structure
4. Extreme dirt can be carefully removed with lukewarm water. REMKO GmbH & Co. KG or your contract partner would Then let the filters air dry. be happy to provide you with the name of a service cen- tre in your area. -
Page 9: Troubleshooting
Troubleshooting This unit has been designed based on state-of-the-art manufacturing methods and it has been tested repeatedly to ensure that it is working properly. However, should problems occur, refer to the following list. Please keep in mind that the indoor units are supplied with power via the outdoor parts. As a result, we recommend also reading the section "Troubleshooting"... -
Page 10: Technical Data
Technical Data RKV 24 W Type RKV 10 W RKV 13 W RKV 18 W See corresponding outdoor part Cooling capacity Area of use room size approx. m³ Refrigerant R 407C Refrigerant pressure max. / min. 2800 / 500 Connection injection line inch (mm) 3/8 (9.52) Connection intake line... -
Page 11: Assembly Instructions For Service Personnel
Make sure that the electrical lines have been prop- à erly attached in the electrical terminals. The indoor unit and outdoor part of the REMKO air- à conditioner have been adjusted to one another from a technical standpoint. -
Page 12: Installation
Installation Attaching the wall mount The unit wall mounts are attached with screws and dow- Make absolutely sure to follow the instructions below els suitable for attachment. prior to assembling the indoor unit: When assembling the indoor unit, make sure that the à... - Page 13 6. Use only the tools below for assembly. 15. If you have selected Option 2 or 4 (drainage through the wall), guide the condensation water and control line through the wall lead-through to the indoor unit. If you also need a condensation pump, it must be in- stalled beforehand.
-
Page 14: Impermeability Check
Impermeability Check Electrical Connection Once all connections have been made, the manometer A 4-wire control line must be led from the indoor unit to station is connected to the corresponding valve connec- the outdoor part. All electrical installations may only be tions as described below: performed by authorised personnel in line with the rele- vant regulations. -
Page 15: Condensation Connection
External Condensation Pump 6. Connect the unit to the current-free line from the out- The condensation pump which can be purchased as an door part. accessory (Ref. no. 1613167) transfers the condensa- See figures. tion which accumulates in the indoor unit to drains that are placed in inconvenient locations, even if the drain is 7. - Page 16 Electrical connection of the condensation pump The electrical connections may only be made by author- The supplied ventilation hose must be used for the res- ised service personnel in accordance with the relevant ervoir to function properly. The end of the ventilation regulations.
-
Page 17: Prior To Initial Operation
Prior to Initial Operation After the pressure check has been performed, the vac- Check the surface temperature of the suction line à uum pump must be connected to the valve connections and determine the evaporator overheating. of the outdoor part (see section “Impermeability Check”) To measure the temperature, hold the thermometer on by means of the manometer station and a vacuum cre- the suction line and subtract the boiling point tempera-... -
Page 18: Environment And Recycling
For the guarantee to be valid, the purchaser or his cus- Important information about recycling! tomer must completely fill out the "guarantee certificate" enclosed with all units and send it back to REMKO GmbH Only authorised personnel may come into contact with & Co. KG the cold cycle. -
Page 19: Initial Operation Certification
Certification for Date 01/2003 Initial operation Subsequent operation of a REMKO air-conditioning system Unit data Outdoor part Indoor unit A Indoor unit B Indoor unit C Indoor unit D Type of unit Unit number Refrigerant line length/height ———– Oil elevation arcs ———–... - Page 20 REMKO GmbH & Co. KG Klima- und Wärmetechnik D-32791 Lage Im Seelenkamp 12 • D-32777 Lage PO Box 1827 • Phone +49 (5232) 606 - 0 +49 (5232) 606260 E-Mail: info@remko.de Internet: www.remko.de...
