6.2. SETTING TYPE OF MOVABLE COLLIMATOR

X-ray unit features the following movable collimators:
- Rectangular 35x45 mm (only with ball joint)
- Round ø55 mm
- Rectangular 31x41 mm (to apply on round collimator ø55 mm)
- Rectangular 22x35 mm (to apply on round collimator ø55 mm)
NOTE: For an ideal use of the x-ray unit, set the collimator depending on the type used.
To set the type of collimator, press keys
Scroll the parameters up to parameter P07 and press key
and then press key
Press key to quit the setup menu.

6.3. RESTORING FACTORY SETTINGS

To restore the factory settings (see paragraph 4.4) press keys
Press keys and
26
and
.
simultaneously. "rESS" will briefly appear and the handheld will be rebooted.
OPERATOR'S MANUAL
to go to the set-up menu.
. Scroll the options to find the type of collimator used
and to go to the set-up menu.
