6.1. SETTING THE OPERATING MODE

X-ray unit features the following operating modes:
- AUTO: the system automatically selects the best setting available for each tooth-patient size combination
- USER: the system automatically proposes the optimum exposure time according to the selected tooth and patient
size - En65: all exposures are performed at 65KV and 6mA.
For both operating modes, the exposure time is in the range 0.02s - 1s. The permitted anode voltage and current
combinations are shown in the following table:
NOTE: This section applies only to models RX DC REF: I3PV*6***
(Character * can be any alphanumeric value)
NOTE: This section applies only to models RX DC REF: I3PV*7***
(Character * can be any alphanumeric value)
To set the operative mode, press keys
Scroll the parameters up to parameter P06 and press key
mode and then press key
Press key to quit the setup menu.
EN
Table 1
60-7 60 kV
63-6 63 kV
65-6 65 kV
Table 2
60-8 60 kV
65-8 65 kV
70-8 70 kV
60-4 60 kV
65-4 65 kV
70-4 70 kV
and to go to the setup menu.
.
OPERATOR'S MANUAL
7 mA
6 mA
6 mA
8 mA
8 mA
8 mA
4 mA
4 mA
4 mA
. Scroll the options to find the desired operating
