5742640-TIM-A-0419
Figure 7: ZDT03 through TA6 Fixed Outdoor Air Motorized Damper Rain Hood Physical Dimensions
Table 4: ZDT03 through TA6 Unit Clearances
Location
Front
Rear
Left Side (Filter Access)
Right Side (Cond. Coil)
1
Below Unit
2
Above Unit
1. Units may be installed on combustible floors made from
wood or class A, B, or C roof covering material.
2. Units must be installed outdoors. Overhanging structures
or shrubs should not obstruct condenser air discharge
outlet.
10
27-1/2
Rear View
Clearance
24" (Cooling/Electric Heat)
32" (Gas Heat)
12" (Less Economizer)
36" (With Economizer or Fixed
Air/Motorized Damper)
24" (Less Economizer)
36" (With Economizer)
24"
0"
72" (For
Condenser Air Discharge)
27-1/2
1-5/8
27-1/2
7-1/4
27-1/2
19-1/8
Dimension "A"
Fixed
Outdoor
12
Air Damper
Motorized
16-1/2
Damper
Filter Access
Blower Motor Access
Dot Plugs
Field-Supplied Disconnect
Switch Location
Figure 8: ZDT03 through TA6 Disconnect Location
19-1/2
44-7/8
Detail "A"
"A"
44-7/8
LH End View
Detail "B"
Mounting Bracket for
Disconnect Switch
A,B
(Field Supplied)
Wiring Entry
(See Detail "B")
Disconne t Switch Location
and Motor Access Panel for
Unit with "Belt-Drive" Option
Johnson Controls Ducted Systems
19-3/4
10-1/4
3-1/2
8-1/4
4-3/8
Control Box Access
