Zdt03 Through Ta6 Unit Limitations; Zdt03 Through Ta6 Component Location - Johnson Controls TempMaster ZD Series Installation Manual

5742640-TIM-A-0419
HACR
Breaker
Economizer
Hood
Knockout
For Side
Power Entry
Slide-In
Economizer
Smoke
Detector
3/4" PVC Female
Condensate Drain
GFCI
Convenience Outlet
Figure 1: ZDT03 through TA6 Component Location
Table 1: ZDT03 through TA6 Unit Limitations
Size
Unit Voltage
(Tons)
208/230-1-60
208/230-3-60
ZDT03
(3.0)
460-3-60
575-3-60
208/230-1-60
208/230-3-60
ZDT04
(4.0)
460-3-60
575-3-60
208/230-1-60
208/230-3-60
ZDT05
(5.0)
460-3-60
575-3-60
208/230-3-60
ZDTA6
460-3-60
(6.0)
575-3-60
6
20 Gauge Aluminized
Steel Tubular Heat Exchanger
Knockout Belt Drive Or
For Side
Direct Drive
Control Entry Blower
SCCR (kVA)
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
Knockout For Side
Gas Supply Entry
Smart Equipment™
Control Board
Unit Limitations
Applied Voltage
Min
187
187
432
540
187
187
432
540
187
187
432
540
187
432
540
Power Ventor Motor With
Post Purge Cycle
Compressor
Full Perimeter Baserails
With Forklift Slots And
Lifting Holes
Outdoor DB Temp
Max Max (°F)
252 125
252 125
504 125
630 125
252 125
252 125
504 125
630 125
252 125
252 125
504 125
630 125
252 125
504 125
630 125
Johnson Controls Ducted Systems
Highly Efficient
Enhanced Copper
Tube/Enhanced
Aluminum Fin
Or
Micro-Channel
Aluminum
Tube/Aluminum
Fin Condenser
