Johnson Controls TempMaster ZD Series Installation Manual page 27

ZDT03 through T05 - With Powered Convenience Outlet (Direct Drive) (Continued)
Compressors
Size
(each)
Volt
(Tons)
RLA LRA
208-1-60 24.4 144.2
230-1-60 24.4 144.2
T05
(5.0)
208-3-60 16 110
230-3-60 16 110
1. Minimum Circuit Ampacity.
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
Johnson Controls Ducted Systems
OD Fan Supply Pwr
Motors Blower Conv
(each) Motor Outlet
MCC FLA FLA FLA
38 4.4 7.6 10
38 4.4 7.6 10
24.9 4.4 7.6 10
24.9 4.4 7.6 10
Electric Heat Option
Model kW Stages Amps
NONE - - -
E05 4 1 19.2
E07 5.6 1 26.9
E10 8 1 38.5
E15 11.9 2 57.2
E20 15.9 2 76.4
E30 22.2 2 106.7
NONE - - -
E05 5.3 1 22.1
E07 7.5 1 31.2
E10 10.6 1 44.2
E15 15.9 2 66.2
E20 21.2 2 88.3
E30 29.6 2 123.3
NONE - - -
E05 4 1 11.1
E07 5.6 1 15.5
E10 8 1 22.2
E15 11.9 2 33
E20 15.9 2 44.1
E30 22.2 2 61.6
NONE - - -
E05 5.3 1 12.7
E07 7.5 1 18
E10 10.6 1 25.5
E15 15.9 2 38.2
E20 21.2 2 51
E30 29.6 2 71.2
5742640-TIM-A-0419
2
Max Fuse /
1 3
MCA Breaker
(Amps) Size
(Amps)
52.5 70
52.5 70
55.7 70
70.1 80
93.5 100
117.6 125
155.4 175
52.5 70
52.5 70
61.1 70
77.2 80
104.8 110
132.4 150
176.2 200
42 50
42 50
42 50
49.8 50
63.3 70
77.2 80
99 100
42 50
42 50
44.6 50
53.9 60
69.8 70
85.7 90
111 125
27
