Johnson Controls TempMaster ZD Series Installation Manual page 25

ZDT03 through TA6 - With Powered Convenience Outlet (Belt Drive High Static) (Continued)
Compressors
Size
Volt (each)
(Tons)
RLA LRA
208-3-60 16 110
230-3-60 16 110
T05
(5.0)
460-3-60 7.8 52
575-3-60 5.7 38.9
208-3-60 19.6 136
230-3-60 19.6 136
TA6
(6.0)
460-3-60 9.4 66.1
575-3-60 7.1 55.3
1. Minimum Circuit Ampacity.
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
4. Single phase, high static belt drive motors not available on gas heating units.
Johnson Controls Ducted Systems
OD Fan Supply Pwr
Motors Blower Conv
(each) Motor Outlet
MCC FLA FLA FLA
24.9 4.4 6.8 10
24.9 4.4 6.8 10
12.1 4.4 3.15 5
8.9 4.4 2.2 4
27 4.4 8.3 20
27 4.4 8.3 20
13 2.4 4.1 20
10 4.4 3.2 20
Electric Heat Option
Model kW Stages Amps
NONE - - -
E05 4 1 11.1
E07 5.6 1 15.5
E10 8 1 22.2
E15 11.9 2 33
E20 15.9 2 44.1
E30 22.2 2 61.6
NONE - - -
E05 5.3 1 12.7
E07 7.5 1 18
E10 10.6 1 25.5
E15 15.9 2 38.2
E20 21.2 2 51
E30 29.6 2 71.2
NONE - - -
E07 6.8 1 8.2
E10 10.1 1 12.1
E15 13.6 2 16.4
E20 19.5 2 23.5
E30 28.8 2 34.6
NONE - - -
E10 10.6 1 10.2
E15 15.9 2 15.3
E20 21.2 2 20.4
E30 30.4 2 29.3
None - - -
E05 4 1 11.1
E07 5.6 1 15.5
E10 8 1 22.2
E15 11.9 1 33
E20 15.9 2 44.1
E30 22.2 2 61.6
None - - -
E05 5.3 1 12.7
E07 7.5 1 18
E10 10.6 1 25.5
E15 15.9 1 38.2
E20 21.2 2 51
E30 29.6 2 71.2
None - - -
E07 6.8 1 8.2
E10 10.1 1 12.1
E15 13.6 1 16.4
E20 19.5 2 23.5
E30 28.8 2 34.6
None - - -
E10 10.6 1 10.2
E15 15.9 1 15.3
E20 21.2 2 20.4
E30 30.4 2 29.3
5742640-TIM-A-0419
2
Max Fuse /
1 3
MCA Breaker
(Amps) Size
(Amps)
41.2 50
41.2 50
41.2 50
48.8 50
62.3 70
76.2 80
98 100
41.2 50
41.2 50
43.6 50
52.9 60
68.8 70
84.7 90
110 125
20.1 25
20.4 25
25.4 30
30.6 35
39.5 40
53.5 60
15.1 20
20.5 25
26.9 30
33.2 35
44.3 45
47.2 60
47.2 60
47.2 60
50.6 60
64.1 70
78 80
99.9 100
47.2 60
47.2 60
47.2 60
54.8 60
70.6 80
86.6 90
111.9 125
23.3 30
23.3 30
26.5 30
31.9 35
40.8 45
54.6 60
17.9 25
21.8 25
28.1 30
34.5 35
45.6 50
25
