R-410A
ZD SERIES
3 - 6 Ton
60 Hertz
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Rigging And Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Compressors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Power And Control Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Typical Field Power and Control Wiring . . . . . . . . . . . . . . . . . . . . 15
Typical Power Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Typical Cool/Heat Control Wiring (Smart Equipment™ ZDT03
through TA6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Optional Electric Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Options/Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
RRS Economizer Interface Overview . . . . . . . . . . . . . . . . . . . 34
Smart Equipment™ Economizer Sequences. . . . . . . . . . . . . . 35
Dry Bulb Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Single Enthalpy Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Dual Enthalpy Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Auto . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Free Cooling Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
1 ZDT03 through TA6 Unit Limitations . . . . . . . . . . . . . . . . . . . . 6
2 ZDT03 through TA6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 ZDT03 through TA6 Unit Accessory Weights . . . . . . . . . . . . . 8
4 ZDT03 through TA6 Unit Clearances . . . . . . . . . . . . . . . . . . 10
5 ZDT03 through TA6 Utilities Entry . . . . . . . . . . . . . . . . . . . . . 11
6 Control Wire Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7 Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
9 ZDT03 through TA6 Physical Data . . . . . . . . . . . . . . . . . . . . 29
10 Electric Heat Minimum Supply Air . . . . . . . . . . . . . . . . . . . . . 31
11 Gas Heat Application Data . . . . . . . . . . . . . . . . . . . . . . . . . . 31
12 Gas Pipe Sizing - Capacity of Pipe . . . . . . . . . . . . . . . . . . . . 32
14 Altitude/Temperature Correction Factors . . . . . . . . . . . . . . . 41
15 ZD Blower Performance Side Duct . . . . . . . . . . . . . . . . . . . . 44
16 ZD Blower Performance Bottom Duct . . . . . . . . . . . . . . . . . . 45
17 Belt Drive RPM Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
18 Indoor Blower Specifications (Belt Drive) . . . . . . . . . . . . . . . 47
1 ZDT03 through TA6 Component Location . . . . . . . . . . . . . . . 6
2 Unit 4 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Unit 6 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Center of Gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Physical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Physical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Hood Physical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . 10
8 ZDT03 through TA6 Disconnect Location . . . . . . . . . . . . . . 10
10 ZDT03 through TA6 Roof Curb . . . . . . . . . . . . . . . . . . . . . . 11
11 Condensate Drain. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
12 Compressor Restraining Bracket . . . . . . . . . . . . . . . . . . . . . 13

TABLE OF CONTENTS

Power Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Checking Supply Air CFM . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Sequence Of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Cooling Sequence Of Operation . . . . . . . . . . . . . . . . . . . . . . . 49
No Outdoor Air Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Cooling Operation Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Electric Heating Sequence Of Operations. . . . . . . . . . . . . . . . 50
Electric Heat Operation Errors . . . . . . . . . . . . . . . . . . . . . . . 51
Gas Heating Sequence Of Operations . . . . . . . . . . . . . . . . . . 52
Gas Heat Operation Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Resets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Start-up (Cooling) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Start-up (Gas Heat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Checking Gas Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Start Up For Units Equipped for FER. . . . . . . . . . . . . . . . . . . . . . 56
Direct Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Belt Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Troubleshooting (Simplicity Lite Only) . . . . . . . . . . . . . . . . . . . . . 57
Start-Up Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
LIST OF TABLES
19 Power Exhaust Specifications . . . . . . . . . . . . . . . . . . . . . . . . 47
20 Additional Static Resistance . . . . . . . . . . . . . . . . . . . . . . . . . 48
21 Electric Heat Limit Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
22 Electric Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . . . . 51
24 2 Stage Gas Heat Limit Control Setting . . . . . . . . . . . . . . . . 53
25 Gas Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . . . . . . . 53
26 Gas Rate-Cubit Feet per Hour . . . . . . . . . . . . . . . . . . . . . . . 56
27 Fan setup commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
28 ZDT03 (3.0 Ton) Operating Pressures . . . . . . . . . . . . . . . . . 59
29 ZDT04 (4.0 Ton) Operating Pressures . . . . . . . . . . . . . . . . . 59
30 ZDT05 (5.0 Ton) Operating Pressures . . . . . . . . . . . . . . . . . 60
31 ZDTA6 (6.0 Ton) Operating Pressures . . . . . . . . . . . . . . . . . 60
33 Ignition Control Board Flash Codes . . . . . . . . . . . . . . . . . . . 65
34 Smart Equipment™ UCB Details . . . . . . . . . . . . . . . . . . . . . 66
35 Cable for FC Buses and SA Buses in Order of Preference . 71
LIST OF FIGURES
14 Side Entry Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
15 Bottom Entry Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
16 Vent And Combustion Air Hood . . . . . . . . . . . . . . . . . . . . . . 34
17 RRS Economizer LCD and Keypad Layout. . . . . . . . . . . . . 34
18 SE-ECO1001-0 Economizer Controller . . . . . . . . . . . . . . . . 37
19 Belt Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
20 Altitude/Temperature Correction Factors . . . . . . . . . . . . . . . 42
21 Pressure Drop Across Coil . . . . . . . . . . . . . . . . . . . . . . . . . . 48
22 Gas Valve Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
23 Typical Single Stage Gas Valves . . . . . . . . . . . . . . . . . . . . . 54
24 Typical 2 Stage Gas Valves . . . . . . . . . . . . . . . . . . . . . . . . . 54
25 Proper Flame Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . 55
26 Typical Flame Appearance . . . . . . . . . . . . . . . . . . . . . . . . . 55
27 Simplicity Lite Control Board . . . . . . . . . . . . . . . . . . . . . . . . 65
28 Smart Equipment™ Unit Control Board . . . . . . . . . . . . . . . . 66

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TempMaster ZD Series and is the answer not in the manual?

Questions and answers

Related Manuals for Johnson Controls TempMaster ZD Series

Summary of Contents for Johnson Controls TempMaster ZD Series

  • Page 1: Table Of Contents

    R-410A ZD SERIES 3 - 6 Ton 60 Hertz TABLE OF CONTENTS General ..........2 Power Exhaust .
