5742640-TIM-A-0419
A
D
Figure 2: Unit 4 Point Load Weight
Figure 4: Center of Gravity
Table 2: ZDT03 through TA6
Weight (lbs.)
Size
(Tons)
Shipping Operating
T03
475 470
(3)
T04
603 598
(4)
T05
637 632
(5)
TA6
670 665
(6)
Table 3: ZDT03 through TA6 Unit Accessory Weights
Unit Accessory
Economizer
Power Exhaust
1
Electric Heat
2
Gas Heat
1. Weight given is for the maximum heater size available (30KW).
2. Weight given is for the maximum number of tube heat exchangers
available (5 tube).
8
C
B
Front
X
LEFT
Center of
4 point Load Location (lbs.)
X Y A B
34.5 18.25 111 80
36 18.5 139 108
37.5 18.2 139 117
35.5 17.75 150 114
Weight (lbs.)
Shipping Operating
55 50
55 50
28 28
70 70
A
F
Figure 3: Unit 6 Point Load Weight
Y
FRONT
6 point Load Location (lbs.)
C D A B
117 162 78 62
154 198 96 81
171 204 96 85
173 228 104 86
C
E
B
Front
C D E F
51 74 91 114
69 98 116 137
76 111 124 140
72 111 132 160
Johnson Controls Ducted Systems
D
