Operations

Front Panel

1. On-line LED and Selected LED:
When the LED turns green, the connected computer
is powered-on. When a computer is selected its
corresponding red LED illuminates.
2. Push buttons:
Each computer has a button associated with it on
the front panel for selection.
Auto Scan
Auto Scan automatically cans through computers one by
one in a fixed interval (see Scan Time below).
Note: keyboard or mouse is not operable during
Auto Scan.
Scan Time
It sets the scan interval for Auto Scan. The Scan Time
options are 3, 8, 15 and 30 seconds.
Note: Scan Time is automatically set to the default of 3
seconds when the KAG switch loses power.
7
