System Requirements

Console
Side
One VGA, SVGA or Multisync monitor
One USB keyboard
One USB mouse

Computer Side

Each USB enabled computer must be connected to the
StarView switch by:
One HDB15 male-to-female VGA cable or monitor
One USB A-B cable with Type-A and Type-B plug for
USB devices, as shown in figure 1.
figure 1: USB A-B cable
(Note: An optional HDB-15 to DB-15 VGA adapter is
required for Mac computer VGA ports)
