Advantech ADAMView Quick Start Manual page 17

In addition, ADAMView 4.25 keeps the runtime from logging the same error messages. This will save
space within the log files and lessen the chance of running out of hard disk space.
(3) Protect Software Against Improper Use and/or Hardware Failure
To protect ADAMView runtime from a strategy that is partially or improperly configured, ADAMView 4.25
requests the user to configure all icons correctly. Partially configured or improperly configured strate-
gies will not be allowed to run in ADAMView 4.25. In addition, this protects ADAMView from hardware
malfunction by isolating the input.
1.4.5 More Enhancements
ADAMView 4.25 provides some new functions, including
(1) A New Basic Script Command
Command
Quit(0)
(2) A New Decimal Formatting Command in Report Designer
This command is used to specify the number of decimal digits in the Report Designer. The old version
is fixed to 2 decimal digits. In ADAMView 4.25, it can be configured by the user. The commands
format is as follows:
COMMAND.N
where "COMMAND" can be $NOW, $HRnn, $MAX, $MAXT, $MIN, $MINT, or $AVE. "N" represents the
number of decimal digits which can be from 0 to 9. For example, if a tag's value is 5.123456789, you
can use the follow commands to format the value:
Command in format file
$NOW(@TASK1#AI1) ms
$NOW(@TASK1#AI1).0 ms
$NOW(@TASK1#AI1).1 ms
$NOW(@TASK1#AI1).9 ms
(3) Network Communication Status in Event Windows and Log Files
For networking communication status, the connection/disconnection messages will show in the Event
window. The will also log into the alarm file (ADAMView.ELF) by enabling the Runtime Preference
event log in ADAMView.
(4) Save and restore previous values
This function is used to save the values of control displays at system stop. These values will then be
restored at the next system start. This function is included in Binary Button Control , Conditional
Button Control, Numeric Control, Knob Control, Slider Control and Log File Block.
12
Description
Stops the overall system
Result
5.12 ms (by default)
5 ms
5.1 ms
5.123456789 ms
