Johnson Controls VRF Smart Gateway Installation Instructions Manual page 14

Table 8: VRF BACnet Points for Outdoor Units
BACnet Object Name
Instance
Number
29 INV-S
30 FAN-S
The following table lists the ODU custom enum values for SYSTEM-MODE.
Table 9: ODU System Mode
Metasys Enum Value
1
2
3
The following table lists the ODU custom enum values for SYSTEM-S.
Table 10: ODU System Status
Metasys Enum Value
1
2
3
4
5
6
7
8
9
10
11
12
13
The following table lists the ODU custom enum values for HX-STATE.
Table 11: ODU Heat Exchanger Status
Metasys Enum Value
1
2
3
4
The following table lists the ODU custom enum values for INV-STATE and FAN-STATE.
Table 12: ODU Inverter and Fan Status
Metasys Enum Value
1
2
VRF Smart Gateway Installation Instructions
Object Description
Inverter Status
Fan Status
Metasys Enum String
Heat
Cool
Auto
Metasys Enum String
Thermo off
Pump down
SW on start
Thermo on start
After defrost
Start control 1
Start control 2
Normal
Oil return
Defrost ready 1
Defrost ready 2
Differential pressure control
Defrost
Metasys Enum String
Evaporator Mode Low Pressure
Condenser Mode High Pressure
Evaporator Mode
Condenser Mode
Metasys Enum String
Normal stop
Fault
Object Type Contents of Information
BI Status Stop
BI Status Stop
Run –
Run –
14
