Items Included in the Upgrade Kit
Check the contents of your kit against the following list. If any part is missing or damaged, contact Keysight
Technologies. Refer to "Getting Assistance from Keysight" on page
Table 1 Contents of Upgrade Kit N5232-60101
Ref
Desig.
-- Installation note (this document)
A29, Test port 1 source 60 dB step attenuator
A30 Test port 2 source 60 dB step attenuator
-- Bracket (for A29 port 1 step attenuator)
-- Bracket (for A30 port 2 step attenuator)
Machine screw, M3 x 8, pan head (to attach brackets to step
--
attenuator assemblies to deck)
-- Cable clamp
-- Front panel overlay
-- Front panel jumper cable guard
-- Dust caps for test ports
W11 RF cable, A21 MASSY to A29 60 dB step attenuator
W12 RF cable, A21 MASSY to A30 test port 2 source attenuator
W13 RF cable, A29 60 dB step attenuator to PORT 1 SOURCE OUT
W14 RF cable, A30 test port 2 source attenuator to PORT 2 SOURCE OUT
W15 RF cable, A25 test port 1 bridge coupler (thru) to PORT 1 CPLR THRU
W16 RF cable, A26 test port 2 bridge coupler (thru) to PORT 2 CPLR THRU
W17 RF cable, A25 test port 1 bridge coupler (arm) to PORT 1 CPLR ARM
W18 RF cable, A21 MASSY to REF 1 SOURCE OUT
W19 RF cable, A21 MASSY to REF 2 SOURCE OUT
W20 RF cable, A26 test port 2 bridge coupler (arm) to PORT 2 CPLR ARM
W21 RF cable, A24 mixer brick to PORT 1 RCVR A IN
W22 RF cable, A24 mixer brick to REF 1 RCVR R1 IN
W23 RF cable, A24 mixer brick to REF 2 RCVR R2 IN
W24 RF cable, A24 mixer brick to PORT 2 RCVR B IN
W30 RF cable, front panel jumper
1. In addition to the upgrade kit, the shipment includes an Option Entitlement Certificate. Refer to
on page 4 for important information about this certificate.
Installation Note N5232-90101
1
Description
attenuators;
3.
Qty
1
2
1
1
to attach
10
14
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
6
"License Key Redemption"
Part Number
N5232-90101
33321-60082
N5235-00013
N5235-00012
0515-0372
1400-1334
N5232-80005
N5242-00029
1401-0214
N5232-20026
N5232-20019
N5232-20027
N5232-20020
N5232-20028
N5232-20021
N5232-20029
N5232-20032
N5232-20025
N5232-20022
N5232-20030
N5232-20031
N5232-20024
N5232-20023
N5222-20091
