Technical Information
PLUS+1 SC0XX-1XX Controller Family
Inputs
A/D refresh rates for SC Controllers
SC Controller
SC024-110/112
SC024-120/122
SC050-120/122
SC050-13H
Digital/Analog/Frequency (DIN/AIN/FreqIN)
General
Description
Response to input below minimum voltage Non-damaging, non-latching; reading saturates to the low limit.
Response to input above maximum voltage Non-damaging, non-latching; reading saturates to the high limit.
Expected measurement
Pull up/pull down configuration
Maximum frequency
Specifications
Description
Allowed voltage at pin
Frequency range
Frequency input when used as quad count or phase shift
Maximum discernable voltage (high range)
Minimum discernable voltage (high range)
Maximum discernable voltage (middle range)
Minimum discernable voltage (middle range)
Maximum discernable voltage (low range)
Minimum discernable voltage (low range)
Precision (high range)
Worst case error (high range)
Precision (middle range)
Worst case error (middle range)
Precision (low range)
Worst case error (low range)
Input impedance (pulled to 5 Vdc or ground, low range)
©
Danfoss | June 2016
A/D refresh rate
All: 1.0 ms
All: 1.0 ms
All: 1.0 ms
All: 1.0 ms
The characteristics of Digital/Analog/Frequency pins are PLUS+1
can be digital, analog or frequency. Inputs can be pulled to 5 Vdc, pulled to ground, pulled to 2.5 Vdc, or
no pull-up/pull-down.
Comment
Frequency (Hz)
Period (0.1 µsec)
Channel to channel phase shift (paired inputs . . . ) (0.1 ms).
PWM duty cycle (0.01%)—Duty cycle measurement only valid up to 5 kHz (FreqIN).
Edge count.
Quadrature count (paired inputs driven from a quadrature encoder).
No pull down/ pull up is standard with pull up or pull down programmable; failure modes are detectable.
The controller may re-boot under some high frequency load conditions above 10 kHz.
®
GUIDE software controlled. The input
Units
Minimum
Maximum
Vdc
0
36
Hz
0
10,000
Hz
0
5000
Vdc
34.1
36.5
mV
0
130
Vdc
5.13
5.38
mV
0
20
Vdc
0.341
0.395
mV
0
12.9
mV
— —
9
Vdc
— —
1.16
mV
— —
1.3
mV
— —
120
mV
— —
90
mV
— —
27
kΩ
13.9
14.3
L1415500 | BC00000235en-US0201 | 9
Comment
In steps of 1 Hz.
In steps of 1 Hz.
35.3 Vdc is typical.
5.26 Vdc is typical.
0.368 Vdc is typical.
