Danfoss PLUS+1 SC0XX-1 Series Technical Information page 11

Technical Information
PLUS+1 SC0XX-1XX Controller Family
Inputs
Specifications
Description
Allowed voltage at pin
Measured resistance
Minimum discernable current
Maximum discernable current
Precision
Worst case error
Input impedance
Maximum over-current protection time at start up (current ≥ 24 mA)
Recover time after over-current protection
Maximum discernable voltage (high range)
Minimum discernable voltage (high range)
Precision (high range)
Worst case error (high range)
Maximum discernable voltage (middle range)
Minimum discernable voltage (middle range)
Precision (middle range)
Worst case error
Input impedance (pulled to 5 Vdc or ground high range)
Input impedance (pulled to 2.5 Vdc high range)
Input impedance (no pull ups high range)
Input impedance (pulled to 5 Vdc or ground middle range)
Input impedance (pulled to 2.5 Vdc middle range)
Input impedance (no pull ups middle range)
© Danfoss | June 2016
Units Minimum Maximum
Vdc 0 36
Ω 0 10,000
mA 0 0.1
mA 25.3 27
µA 6
µA 868
Ω 198.6 202.6
ms 100
s 5.4
Vdc 25.3
mV 0 130
mV 9
Vdc 1.16
Vdc 5.13 5.38
mV 0 20
mV 1.3
mV 120
KΩ 13.0 13.4
KΩ 6.9 7.1
KΩ 108 112
KΩ 13.9 14.3
KΩ 7.2 7.4
KΩ 230 236
Comment
Over the full temperature range
-40°C to 85°C (-40°F to 185°F)
Over the full temperature range
-40°C to 85°C (-40°F to 185°F)
Over the full temperature range
-40°C to 85°C (-40°F to 185°F)
L1415500 | BC00000235en-US0201 | 11
