3 - Installation

3.3.2 How to Connect eDynamo to an iOS Host via Bluetooth LE

To connect eDynamo to an iOS host that supports Bluetooth LE, follow these steps:
1) If any Bluetooth LE host software has an active data connection to the device, close the connection.
2) On the host, install and configure the host software you intend to use with eDynamo. If you do not
yet have that software, you can download a test tool from the App Store called
published by
MagTek, Inc.
3) Make sure eDynamo's battery is adequately charged (see section 3.2 About Power for instructions).
4) Make sure the eDynamo output connection is configured to transmit card data over Bluetooth LE.
This is the factory default.
5) Press the pushbutton for 2 seconds until the Bluetooth Status LED starts flashing. The Bluetooth
Status LED flashes blue once per second for up to 60 seconds, or until a host pairs or connects.
6) On the iOS host, launch the
radio is turned On .
7) Use the host application or the
device. If you are using the
similar:
a) Launch the host software app.
b) Select eDynamo
c) Press the
Connect
d) Locate the seven-digit serial number on the label on the bottom of the device.
e) In the list of pairable devices, select
number.
8) When the host pops up a
configured passkey (or one of the defaults,
now Connected .
eDynamo| Secure Card Reader Authenticator | Installation and Operation Manual
.
app, select
Settings
MagTek Test
app, the steps are as follows. Other host software may be
MagTek Test
as the device type.
button.
eDynamo-xxxxxxx
Bluetooth Pairing Request
999999
Page 16 of 34 (D998200110-23)
, and make sure the host's Bluetooth
Bluetooth
app (not the device's
Settings
, where xxxxxxx
message asking for a code, enter the
or ). The app should report the device is
000000
MagTek Test ,
app) to pair with the
is the device's serial
