- Page 1 INSTALLATION & MAINTENANCE GUIDE Low Voltage Landscape Lighting ® Silhouette Integrated LED Path Light ® APL-3011-4-B-BZ Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m...
-
Page 2: Important Safety Instructions
Silhouette Integrated LED Path Light ® A. (1) Fixture A. (1) XL Hammer Stake APL-3011-4-B-BZ B. (1) Stake B. (1) LED Puck Light (pre-installed) Important Safety Instructions: Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). - Page 3 INSTALLATION & MAINTENANCE GUIDE INSTALLATION & MAINTENANCE GUIDE Silhouette Integrated LED Path Light ® Silhouette Integrated LED Path Light ® APL-3011-4-B-BZ APL-3011-4-B-BZ Wire Connections Install Stake Determine the desired location for mounting Pigtail Board the fixture. Hammer the stake into the Wire Connectors ground until flange of stake is flush to grade.
- Page 4 Specifications and product details subject to change without notice. © Copyright 2019, AMP Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@amplighting.com • 813.978.3900 w w w. a m p l i g h t i n g . c o m IS-APL-3011-4-B-BZ-ver1.pdf...
