Summary of Contents for AMP Lighting APL-3015-B-BZ
- Page 1 Low Voltage Landscape Lighting ® Dual Mini PinnaclePro Path Light (Lamp - Ready) ® APL-3015-B-BZ Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m...
- Page 2 INSTALLATION & MAINTENANCE GUIDE Package Contents Dual Mini PinnaclePro Path Light (Lamp Ready) ® A. (1) Fixture Body APL-3015-B-BZ B. (2) Stake Important Safety Instructions: Read Before Installation Parts Required This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC).
- Page 3 INSTALLATION & MAINTENANCE GUIDE Install Shield and Glare Guard ® Dual Mini PinnaclePro Path Light (Lamp Ready) APL-3015-B-BZ Fixture Body Place the shield over the lamp and thread onto the fixture. Attach the Install Stake Shield glare guard back onto the shield and secure with the set screw.
- Page 4 Dual Mini PinnaclePro Path Light (Lamp Ready) ® Install/Replace Lamp APL-3015-B-BZ Loosen the set screw on glare guard, remove the glare guard and the shield to expose the lamp. Replace it with the correct wattage and type marked on the fixture label. Then reinstall the shield and glare Wire Connections guard and tighten with the set screw.
