- Page 1 INSTALLATION & MAINTENANCE GUIDE Low Voltage Landscape Lighting ® OrchardPro Path Light (Lamp - Ready) ® APL-3018-B-BZ Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m - 1 -...
- Page 2 INSTALLATION & MAINTENANCE GUIDE Package Contents OrchardPro Path Light (Lamp - Ready) ® A. (1) Fixture Body D. (1) LED Lamp APL-3018-B-BZ B. (1) Shade E. (1) Diffuser Important Safety Instructions: Read Before Installation C. (1) Stake This fixture is intended for installation in accordance with local codes and the National Electric Code (NEC).
- Page 3 INSTALLATION & MAINTENANCE GUIDE Wire Connection OrchardPro Path Light (Lamp - Ready) ® APL-3018-B-BZ Pigtail Wire Connectors Install Stake Main Supply Cable Determine the desired location for mounting Board the luminaire. Hammer the stake into the ground until flange of stake is flush to grade. To avoid damage to the stake, place a board on top of the stake while hammering.
- Page 4 INSTALLATION & MAINTENANCE GUIDE OrchardPro Path Light (Lamp - Ready) ® APL-3018-B-BZ Install Dome Lens Holder Thread the dome lens back onto the holder and hand tighten. Dome Lens Install/Replace Bulb Please reference Step 4 - Step 6 to expose the Bulb and replace it with the correct wattage and type marked on the fixture label.
- Page 5 Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) Specifications and product details subject to change without notice. © Copyright 2019, AMP Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@amplighting.com • 813.978.3900 w w w. a m p l i g h t i n g . c o m - 8 -...
