ST EP 6
Attach Keyboard Platform
• Attach the keyboard platform to the lower
arm using four M6 x 10mm countersink screws
and the included metal plate.
ST EP 7
Attach Lower Arm to Base
• Remove the 180° stop screw from
the M8 arm head. (fig. E)
• Place the lower arm with keyboard
platform into the M8 arm socket and
re-insert the 180° stop screw. (fig. F)
ST EP 8 (IF CONFIGUR ED W IT H A C ROSSBA R)
Attach Crossbar
• Attach the monitor crossbar to the upper
arm using 2 M5 x 14mm screws and one
M6 x 14mm screw.
E F
5
