SCOPIA
Gateway Quick Start
100
Version 5.6

Advertisement

Table of Contents
loading

Summary of Contents for RADVision SCOPIA 100

  • Page 1 SCOPIA Gateway Quick Start Version 5.6...
  • Page 2 If there is any software on removable media described in this publication, it is furnished under a license agreement included with the product as a separate document. If you are unable to locate a copy, please contact RADVISION Ltd and a copy will be provided to you.
  • Page 3: What's In This Guide

    Quick Start ’ This Quick Start provides the basic steps required for getting your S IN THIS SCOPIA Gateway up and running: UIDE The suggested order of operation is as follows: Unpack and Verify the Equipment Prepare a Checklist Prepare the Site Mount the SCOPIA100 Gateway Unit in a 19"...
  • Page 4 SCOPIA Gateway Quick Start SCOPIA Gateway Release Notes Utilities and Documentation CD-ROM containing product documentation, utilities and online help files. Before you start configuration, fill in the checklist below. REPARE A HECKLIST ISDN N PRI/BRI Service Provider ETWORK IRECTORY Service Provider: ______________________ (PRI UMBERS BRI G...
  • Page 5 ISDN N Channel Rate ETWORK HYSICAL (PRI NTERFACE 56 Kbps 64 Kbps ATEWAYS ONLY Port 1 56 Kbps 64 Kbps 56 Kbps 64 Kbps Port 2 56 Kbps 64 Kbps Carrier/Switch Signaling Protocol Euro ISDN 5ESS Port 1 DMS100 Nat ISDN 5ESS 4ESS Euro ISDN...
  • Page 6 Line Coding HDB3 Port 1 B8ZS AMI-B7 HDB3 Port 2 B8ZS AMI-B7 Line Framing CRC4 Double framing Port 1 Extended CRC4 ESF no CRC ESF CRC6 JT CRC4 Double framing Port 2 Extended CRC4 ESF no CRC ESF CRC6 JT 4 SCOPIA Gateway Quick Start...
  • Page 7 ISDN N Carrier/Switch Signaling Protocol ETWORK HYSICAL (BRI NTERFACE DMS100 Nat ISDN 5ESS ATEWAYS ONLY Port 1 5ESS PTP ETSI ETSI PTP Austel 1 Hong Kong DMS100 Nat ISDN 5ESS Port 2 5ESS PTP ETSI ETSI PTP Austel 1 Hong Kong DMS100 Nat ISDN 5ESS...
  • Page 8: Prepare The Site

    DTE/DCE Interface Configuration Options ERIAL HYSICAL NTERFACE ERIAL Terminal Adaptor Signaling Protocol ATEWAYS ONLY Interface Options Options Common RS-366 Manual Control Data Triggered KG-Device RS-366 Manual Control Data Triggered Common RS-366 IP N Network Addressing ETWORK HECKLIST Gateway IP address _ _ _ . _ _ _ . _ _ _ . _ _ _ IP Mask (subnet mask) _ _ _ .
  • Page 9 You can optionally mount the SCOPIA Gateway unit in a OUNT THE SCOPIA standard 19-inch rack. Two mounting brackets and a set of screws are included in the SCOPIA Gateway unit shipping ATEWAY NIT IN 19" R box. PTIONAL Procedure Disconnect all cables including the power cables.
  • Page 10 Insert the SCOPIA Gateway unit into the 19- inch rack. Fasten the brackets to the side rails of the rack. Make sure that the air vents at the sides of the SCOPIA Gateway unit are not blocked. The first time you install the Gateway, you assign an IP address SSIGN AN DDRESS TO THE using a terminal cable connection.
  • Page 11: Connect To Apc

    You make the serial connection by connecting a PC terminal ONNECT TO A equipped with a terminal emulation application to the front panel serial port of the Gateway. Procedure Run a terminal emulation application (such as HyperTerminal) on the PC. Configure the communication settings for the PC serial port as follows: 9600 Baud rate...
  • Page 12 Press any key during the six-second countdown to enter the configuration menu. The network configuration Main menu displays as shown at Figure 2. If you do not press a key before the countdown ends, the Gateway continues its initialization and you can only configure the Gateway by pressing the Reset button on the front panel.
  • Page 13: Configuring An Ip Address

    ONFIGURING AN DDRESS Procedure At the colon type N. The Default Network Port Values screen (Figure displays. Enter IP Address for Interface No. 1 Without leading zeros < 172.27.20.194>: Enter Default Router IP Address Without leading zeros < 172.27.37.254>: Enter IP Mask Without leading zeros <...
  • Page 14: Connect To The Ip Network

    Use the supplied LAN cable to connect the Ethernet IP network ONNECT TO THE IP N port on the front panel of the Gateway to a 10/100Base-T IP ETWORK network connection on your network hub. ONNECT TO THE Use the appropriate cables to connect the PRI/BRI ISDN ports to ISDN N ETWORK your PBX or direct PRI/BRI line connection.
  • Page 15: Check The Network Settings

    Enter your user name and password and click OK to proceed to the configuration page. The default user name is admin and the default password is null. The configuration interface displays. Use the web interface to check that the network addresses you HECK THE ETWORK DDRESS...
  • Page 16 The Gateway is pre-programmed with a number of default ATEWAY ERVICES service prefixes used in outgoing calls. You can modify the existing prefixes to suit your network environment or define new services and add them to the list. Before setting a Gateway service, consider the following: Ensure that the service prefix numbers are not identical to the first digits of any of your IP network endpoint phone numbers or aliases.
  • Page 17 If your Gateway supports two PRI ports, enable the second PRI port and define the phone numbers used for that port. Check the Same as Port checkbox to duplicate the settings from the first PRI port in each of the remaining sections: Physical Interface, Advanced ISDN, Call Policies and Supported Services.
  • Page 18: Save The Configuration

    Procedure In the Gateway interface Port tabs Basics section, enable the required port. In the Physical Interface, Call Policies and Supported Services sections, define the settings you want for this port. Follow your checklist to help organize the settings. Enable additional ports as required. Check the Same as Port checkbox in the Physical Interface section to duplicate the settings from the first serial port in each of the...
  • Page 19 When a call is connected, the front panel LED lights up. If you are not able to complete the trial calls, refer to the Troubleshooting chapter in the SCOPIA Gateway User Guide. Dialing Example 1 Voice calls (PRI and BRI Gateways only) From an IP phone on the IP network, dial the Gateway service prefix for voice calls and the destination phone number.
  • Page 20 * is the second number delimiter. 1816455319 is the second B channel number including the area code. Dialing Example 4 384 Kbps bonded call From a videoconferencing endpoint on the IP network, dial the Gateway prefix for 384 Kbps bonded calls and the phone number of the destination Gateway or H.320 room system.
