Cisco IP Conference Phone 8832 PoE Injector
with the PoE power option.

Connect to the Network

You need to connect the phone to the telephone network.
• Wired connection—the phone is plugged into the network using an Ethernet cable.

Install the Wired Expansion Microphones

The conference phone supports an optional kit with two wired expansion microphones. You can extend the
microphones up to 7 feet (2.13m) from the phone. For best results, we recommend that the microphones be
placed at least 3 feet (0.91m) away from the phone.
Note: You must use either two wired microphones or two wireless microphones with the phone, but not a mixed
combination.
Procedure
Step 1 Plug the end of the microphone cable into the port on the side of the conference phone.
Step 2 Extend the microphone cable to the desired position.
The following figure shows installation of a wired expansion microphone.
Figure 3: Wired Expansion Microphone Installation

Install the Wireless Expansion Microphones

The conference phone provides the option of connecting two wireless expansion microphones.
Note: You must use either two wired microphones or two wireless microphones with the phone, but not a mixed
combination.
When the phone is in a call, the LED on the expansion microphone is lit green. To mute the expansion
microphone, press the Mute key. When the microphone is muted, the LED is lit red. When the battery in the
microphone is low, the battery indication LED blinks rapidly.
Before you begin
3 |
P a g e
Cisco IP Phone 8832 Series User Guide
