Solarcheck family
88
PHOENIX CONTACT
Table A-2 Register contents for the SCK-C-MODBUS
Modbus address (HEX)
0480
0481
0482
0483
0484
0490
0491
0492
0493
0494
0495
0496
0497
0498
0499
04A0
04AE
04AF
04B0
04B1
04B2
04B3
04B4
04B5
04B6..04C5
Table A-3 SCK-M-I-8S-20A register contents
Index Designation
Channel status
PD0 Digital input
PD1 Current channel 1
PD2 Current channel 2
PD3 Current channel 3
PD4 Current channel 4
PD5 Current channel 5
PD6 Current channel 6
PD7 Current channel 7
PD8 Current channel 8
PD9 Temperature
PD10 Voltage
PD11...PD47 Unused
Designation
SCK-C PD0 (short circuit)
SCK-C PD1 (not connected)
SCK-C PD2 (communication error)
SCK-C PD3 (ready for operation)
SCK-C PD4 (switched off)
SCK-C PD16 (avg. request interval)
SCK-C PD17 (number of packet requests)
Number of packet errors SCK channel 1
Number of packet errors SCK channel 2
Number of packet errors SCK channel 3
Number of packet errors SCK channel 4
Number of packet errors SCK channel 5
Number of packet errors SCK channel 6
Number of packet errors SCK channel 7
Number of packet errors SCK channel 8
SCK-C PD32 (temperature)
SCK-C PD46 (switch off SCK IF)
SCK-C PD47 (identify module)
SCK-C PD48 (comp. level)
SCK-C MI0 (module ID)
SCK-C MI1 (serial number)
SCK-C MI2 (serial number)
SCK-C MI3 (serial number)
SCK-C MI4 (serial number)
SCK-C MI5..MI20 (name, 32 x ASCII)
Data type Value range
Bit mask
USIGN16 0..1
INT16 -250..2500
-250..2500
-250..2500
-250..2500
-250..2500
-250..2500
-250..2500
-250..2500
-50..100
-2000..12000
Unit
-
A/100
A/100
A/100
A/100
A/100
A/100
A/100
A/100
°C
mV
105608_en_00
